Mini Skate Sealed Durable Transmission Bearing 624zz Anti Corrosion
Mini Skate Deep Groove Ball Bearing 624zz
Product Description:
Deep groove ball bearings have a groove on the outside and the inside of the bearing. These grooves reduce strain on the bearings, so they can take heavier loads and operate in high-speed conditions.These type of bearings can be used in any machine that uses ball bearings to avoide heavy friction. These includes agricultural machinery, construction equipments, etc.
Applications: Deep groove ball bearing can be used in any machine that uses ball bearing to heavy friction.These include agricultural machinery, construction equipment, etc.
Feature of deep groove ball bearing:
1. AISI420C stainless steel races
2. AISI304 stainless steel cage/Nylon cage
3. Stainless steel balls
4. Dry lube/ Grease/ Oil
5. Rubber seals/ ZZ metal shields
6. High speed
7. Long spin time
8. Low friction
9. Rustproof and corrosion resistance
10. Durable
11. Easy to maintenance
Application:
Deep groove ball bearings can be used for: transmission, instrumentation, motors, household appliances, internal combustion engines, transport vehicles, agricultural machinery, construction machinery, construction machinery, roller skates, yo-yo.
Dimensions of Sealed bearing
| Bearing Number | Boundary Dimensions(mm) | Basic Load Ratings(kN) | Limiting Speeds(rpm) | Mass(Kg) | |||||
| d | D | B | rs min | Cr | Cor | Grease | Oil | (Approx.) | |
| 623zz | 3 | 10 | 4 | 0.6 | 8.2 | 3.5 | 23,000 | 27,000 | 0.053 |
| 624zz | 4 | 13 | 5 | 1 | 9.7 | 4.2 | 20,000 | 24,000 | 0.006 |
| 625zz | 5 | 16 | 5 | 1 | 11.4 | 5.45 | 17,000 | 21,000 | 0.008 |
| 626zz | 6 | 19 | 6 | 1 | 13.5 | 6.55 | 16,000 | 19,000 | 0.009 |
| 627zz | 7 | 22 | 7 | 1.1 | 15.9 | 7.9 | 14,000 | 17,000 | 0.01 |
| 628zz | 8 | 24 | 8 | 1.1 | 21.2 | 10.9 | 12,000 | 14,000 | 0.01 |
| 629zz | 9 | 26 | 8 | 1.1 | 26.7 | 15 | 10,000 | 12,000 | 0.015 |
| 634zz | 4 | 16 | 5 | 1.5 | 33.5 | 19.1 | 8,800 | 10,000 | 0.017 |
| 635zz | 5 | 19 | 6 | 1.5 | 40.5 | 24 | 7,800 | 9,200 | 0.018 |
| 603zz | 3 | 9 | 4 | 1.5 | 53 | 32 | 7,000 | 8,200 | 0.019 |
| 604zz | 4 | 12 | 4 | 2 | 62 | 38.5 | 6,400 | 7,500 | 0.001 |
| 605zz | 5 | 14 | 5 | 2 | 71.5 | 45 | 5,800 | 6,800 | 0.002 |
| 606zz | 6 | 17 | 6 | 2.1 | 82 | 52 | 5,400 | 6,300 | 0.005 |
| 607zz | 7 | 19 | 6 | 2.1 | 92.5 | 60 | 4,900 | 5,800 | 0.007 |
| 608zz | 8 | 22 | 7 | 2.1 | 104 | 68 | 4,600 | 5,400 | 0.010 |
| 609zz | 9 | 24 | 7 | 2.1 | 113 | 77 | 4,300 | 5,000 | 0.015 |
| 6000zz | 10 | 26 | 8 | 2.1 | 123 | 86.5 | 4,000 | 4,700 | 0.017 |
| 684zz | 12 | 28 | 8 | 3 | 133 | 97 | 3,800 | 4,500 | 0.020 |
| 685zz | 5 | 11 | 5 | 3 | 143 | 107 | 3,600 | 4,200 | 0.021 |
| 686zz | 6 | 13 | 5 | 3 | 153 | 119 | 3,300 | 3,900 | 0.022 |
| 687zz | 7 | 14 | 5 | 3 | 173 | 141 | 3,200 | 3,700 | 0.028 |
