6415ZZ 2RS Deep Groove Ball Bearing Singel Row For Roller Skates
6415ZZ 6415 2RSOPEN Size 75*190*45mm Deep groove ball bearing
Gearboxes, instrumentation, motors, household appliances, internal combustion engines, transportation vehicles, agricultural machinery, construction machinery, construction machinery, roller skates, yo-yo, etc..
An outer ring, an inner ring and a deep groove in the middle are lined with rolling steel balls, so it is called deep groove ball bearing.
The interface radius of the channel located on the inner and outer rings is slightly larger than the radius of the sphere. Mainly can bear radial load.
Application:
Deep groove ball bearings can be used for: transmission, instrumentation, motors, household appliances, internal combustion engines, transport vehicles, agricultural machinery, construction machinery, construction machinery, roller skates, yo-yo.
| 6400 series | ||||
| (mm) | (kg) | |||
| Bearing No. | d | D | T | Weight |
| 6401 | 12 | 42 | 13 | 0.098 |
| 6402 | 15 | 52 | 16 | 0.010 |
| 6403 | 17 | 62 | 17 | 0.270 |
| 6404 | 20 | 72 | 19 | 0.400 |
| 6405 | 25 | 80 | 21 | 0.530 |
| 6406 | 30 | 90 | 23 | 0.720 |
| 6407 | 35 | 100 | 25 | 0.920 |
| 6408 | 40 | 110 | 27 | 1.170 |
| 6409 | 45 | 120 | 29 | 1.570 |
| 6410 | 50 | 130 | 31 | 1.880 |
| 6411 | 55 | 140 | 33 | 2.250 |
| 6412 | 60 | 150 | 35 | 2.800 |
| 6413 | 65 | 160 | 37 | 3.440 |
| 6414 | 70 | 180 | 42 | 5.000 |
| 6415 | 75 | 190 | 45 | 5.570 |
| 6416 | 80 | 200 | 48 | 6.640 |
| 6417 | 85 | 210 | 52 | 8.130 |
| 6418 | 90 | 225 | 54 | 9.800 |
| 6420 | 100 | 250 | 58 | 15.400 |
| 6422 | 110 | 280 | 65 | 19.00 |
