Heavy Zinc Coating BTO-60 Barbed Tape Concertina Wire , Razor Blade Barbed Wire
heavy zinc coating BTO-60 concertina razor blade barbed tape steel wire,razor fencing wire introduction
BTO-60 razor barbed tape wire is a kind of modern security fencing materials fabricated with razor-sharp steel blade and high-tensile wire lassifications:Galvanized barbed wire,PVC coated barbed wire and stainless steel barbed wire.
Razor wire types: stright line razor wire, single coil conertina wire, double coil wire, welded razor mesh fence.
Applications:mainly serves in protecting of grass boundary,railway,highway and also widely used in military,jail,industry,agriculture,animal husbandry,dwelling house,plantation for fencing
heavy zinc coating BTO-60 concertina razor blade barbed tape steel wire,razor fencing wire detail:
The BTO-60 razor barbed tape wire materil:
1.hot dipped galvanized,heavy zinc coated and linght zinc coated.
2.PVC powder coated,color:green or wihite
3.stainless steel materil,302,304,316L 316 and so on.
heavy zinc coating BTO-60 concertina razor blade barbed tape steel wire,razor fencing wire technical sheet
| NAME | DETAIL | DATE |
| BLADE AND WIRE | BLADE THICKNESS | 0.6MM±0.05MM |
| INNER WIRE | 2.5MM±0.1MM | |
| BLADE LENGTH | 60MM±2MM | |
| BLADE WIDTH | 32MM±1MM | |
| BLADE DISTANCE | 100MM±2MM | |
| BLADE AND WIRE ZINC COATED | ≥40G/M2 | |
| WIRE STRENGTH | 400MPA-600MPA | |
| ROLL | ROLL DIAMETER | Φ70CM |
| CLIPS OF EACH LOOP | 5 | |
| DISTANCE OF EACH LOOP | 10CM | |
| WEIGHT OF EACH LINER METER | 5.5KG±0.1KG | |
| PACKING | WATERPROOF PAPER INSIDE,WOVEN BAG OUTSIDE. |
