VOE14542103 Ring heavy parts EC700B, EC700C
1. Quick Details of seal VOE14542103:
| Part NO. | VOE14542103 |
| Machine | excavator |
| Size | OEM |
| Material | PTFE |
| Type | RING SEAL |
2. VOE14542103 parts on group :
| NO. | PART NO. | PRAT NAME | QTY |
| VOE14564684 | Cylinder | 1 | |
| 1 | VOE14542108 | Bushing | 2 |
| 2 | VOE14542090 | Rod | 1 |
| 3 | VOE14542108 | Bushing | 2 |
| 4 | VOE14542093 | Ring | 1 |
| 5 | VOE14542094 | Ring | 1 |
| 6 | VOE14542095 | Ring | 1 |
| 7 | VOE14542096 | Ring | 1 |
| 8 | VOE14542097 | Ring | 1 |
| 9 | VOE14585343 | Ring | 1 |
| 10 | VOE14542099 | O-ring | 1 |
| 11 | VOE14542100 | Ring | 1 |
| 12 | VOE14542022 | Bolt | 8 |
| 13 | VOE14542101 | Ring | 1 |
| 14 | VOE14542103 | Ring | 1 |
| 15 | VOE14542104 | Ring | 2 |
| 16 | VOE14542105 | Ring | 2 |
| 17 | VOE14542106 | Nut | 1 |
| 18 | VOE14542068 | Set screw | 1 |
| 19 | SA9676-71600 | Ball | 1 |
| 20 | VOE14542032 | Ring | 4 |
| 21 | VOE14542033 | Venting | 1 |
| 22 | VOE14542092 | Bushing | 1 |
| 23 | VOE14589339 | Sealing kit | 1 |
3. VOE14542103 picture:
4. Service part number :
| PART NO. | PART NO. | Part NO. |
| 3K-0360 | 6V-8398 | 7F8268 |
| 206-9298 | 3K-0360 | 6V-9746 |
| 8T-9597 | 5J-8825 | 8T-2361 |
| 236-6919 | 1J-6474 | 7F-8607 |
5. FAQ
Q: Which construction machinery does VOE14542103 fit?
A: VOE14542103 is a piston seal ring manufactured for excavator bucket hydraulic cylinder.
Q: What materials are used to produce VOE14542103 piston seal ring?
A: VOE14542103 piston seal ring uses filled PTFE sealing layer paired with NBR back-up ring.
Q: What is the main sealing task of this piston seal ring?
A: It separates pressure on two sides of piston to prevent internal oil leakage inside cylinder tube.
Q: Where do we install this piston seal ring on the bucket cylinder?
A: It sits in the machined piston groove of the bucket cylinder hydraulic assembly.
Q: What performance feature does NBR material provide for this seal set?
A: NBR shows stable compatibility with mineral hydraulic oil and good elasticity under pressure.
Q: What kind of working cycles can this piston seal ring sustain?
A: It can adapt to frequent loading and unloading cycles during excavation and material grabbing work.
Q: What warning sign tells us this piston seal ring needs replacement?
A: The bucket will drift down gradually and digging force will drop when the seal is worn.
