Shield Wire Ceramic Ultrasonic Transducer 3.0Mpa Ceramic Piezo Transducer
MOQ:
1000 pieces
Delivery Time:
10-15 days
Brand:
Runpaq
Product Description
ceramic ultrasonic transducer, ultrasonic water meter housing
General description:
The piezoelectric ceramic products design, developing, and production. Based on our advanced technology, and production flow process, our piezo transducer are widely used in ultrasonic cleanting, welding, detection, B-medical, beauty equipment, acoustic transducer, micro driven, ultrasonic flowmeter, and many other fields.
Product data sheet
| Technical parameters | |||||
| Model | 10A | Center frequency | 975 + 30 KHz | Static capacity | 400 PF + 20% |
| Resonance impedance | <110 Ω | Protection | IP68 | Work temp. | < 75 ℃ |
| Pressure | >3.0 Mpa | Transmit beam angle | 5 – 10 | Receive | >120 mv |
| Housing material | SS304+Polymer | Emit surface | Dia. 10 mm | Mounting surface | Dia. 15 mm |
| Seal | Epoxy | Wiring | Center | Wire type | Shield wire |
| Technical parameters | |||||
| Model | 17B | Center frequency | 975 + 30 KHz | Static capacity | 500 PF + 20% |
| Resonance impedance | <110 Ω | Protection | IP68 | Work temp. | < 90 ℃ |
| Pressure | >3.0 Mpa | Transmit beam angle | 5 – 10 | Receive | >300 mv |
| Housing material | SS304+polymer | Emit surface | Dia. 17 mm | Mounting surface | Dia. 21 mm |
| Seal | Epoxy | Wiring | Center | Wire type | Dia. 2.5 mm |
Parameters
Different options:
