Shield Wire Waterproof Ultrasonic Sensor SS304 Piezoelectric Ceramic Sensor
MOQ:
1000 pieces
Delivery Time:
10-15 days
Brand:
Runpaq
Product Description
brass ultrasonic water meter housing, ultrasonic transducer, ceramic sensor
General description:
The range of our piezoelectric transducers are developed by us. The ultrasonic transducers are widely used in the fields of: such as ultrasonic cleaning, welding, testing, B-ultrasound medical treatment, beauty equipment, acoustic transducers, micro-drives, ultrasonic flowmeters and so on. Design, development and production of piezoelectric ceramic products. Based on our advanced technology and production process.
Product data sheet
| Technical parameters | |||||
| Model | BX17 | Center frequency | 975 + 30 KHz | Static capacity | 600 PF + 20% |
| Resonance impedance | <110 Ω | Protection | IP68 | Work temp. | < 90 ℃ |
| Pressure | >3.0 Mpa | Transmit beam angle | 5 – 10 |
Receive sensitivity |
>250 mv (half wave) |
| Housing material | SS304 | Emit surface | Dia. 17 mm | Mounting surface | Dia. 21 mm |
| Seal |
Epoxy encapsulation |
Wiring | Center | Wire type |
Dia. 2.5 mm dual core |
| Technical parameters | |||||
| Model | 17A | Center frequency | 975 + 30 KHz | Static capacity | 500 PF + 20% |
| Resonance impedance | <110 Ω | Protection | IP68 | Work temp. | < 90 ℃ |
| Pressure | >3.0 Mpa | Transmit beam angle | 5 – 10 |
Receive sensitivity |
>250 mv (half wave) |
| Housing material | Brass | Emit surface | Dia. 17 mm | Mounting surface | Dia. 21 mm |
| Seal |
Epoxy encapsulation |
Wiring | Center | Wire type |
Dia. 2.5 mm dual core |
Parameters
Different options:
