More Effective and Visual Mixed CN-S04 -C Crystal Baskatball Flooring
Product Description
The purpose of building sports courts is to ensure a professional, safe, healthy sports condition-the characteristics of hardness will bring the professional sporting feeling; the cushion effectively increasing the shock absorption and reduce the incidence of injuries to ankles, joints and ligaments. At the same time, it should reduce abrasion caused by falling and accident.
It’s a design based on human kinetics and physical characteristics flooring system, with hard top layer combined with soft rebound cushion lower layer structure. It’s suitable to lay on concrete or asphalt substrates. The cushion layer is formed by single component modified polyurethane and top up with two-component modified acrylic resilience layer.
SPU acrylic tennis court system uses modified tenacious acrylic resin as the abrasion resistant layer. It’s a
breakthrough for the brittleness and fissility shortcomings of the traditional acrylic material.
Polymer compound material supports the surface layer well and its excellent ductility plays an effective role in
dynamic anti-crack performance.
To promote the sport profession and protection advantage of the traditional acrylic floor
To improve the weakness of the traditional acrylic floor, durable and professional.
The quality of the production is validated by international events and it is qualified by the State Administration
of Environment Protection's product certification.
Excellent Performance
1. Buffering effect given by resilience protects the athletes’ joints and reduces sport injury.
2. The surface layer of acrylic cushion provides certain protection to accidental falls in sports.
3. The tennis court with buffering effect has a longer sport life.
4. The resilient tennis courts provide more stable ball speed and ball direction. The sport felling is better.
5. The surface layer of the acrylic cushion tennis court provides more comfortable sporting texture when athletes are
starting, stopping abruptly or sliding.
Sports Performance Data
| NO. | items | index of standard | results |
| 1 | value of rebound, % | ≥80 | 88 |
| 2 | impact absorption | 5~15 | 9 |
| 3 | Slid friction, N | 60~100 | 76 |
| 4 | Water permeability, mm/min | 0 | 0 |
Pysical Properties Data
| NO. | items | index of standard | results | |
| 1 | Tensile elongation, % | ≥400 | 857 | |
| 2 | tensile strength, MPa | ≥1.8 | 3.2 | |
| 3 | artificial weathering ageing resistance d(300h) | No bubble, no peeling, no crack; Powder ≤grade 1, △E≤5.0 | No bubble, no peeling, no crack; Powder ≤grade 1, △E=0.9 | |
| 4 | Durability, aging test (168h) | Tensile elongation, % | ≥300 | 858 |
| tensile strength, MPa | ≥1.3 | 1.6 | ||
| 5 | wearability(750g/500r)/g | ≤0.050 | 0.035 | |
| 6 |
water resistance
|
No bubble, no peeling, allows slight discoloration, recover after 2h | No bubble, no peeling, no discoloration | |
| 7 | Flame retardancy, class | Ⅰ | Ⅰ | |
Health and Environmental Properties Data
| NO. | items | index of standard | results | |
| 1 | volatile organic compound content (VOC) (g/l) | ≤670 | 104 | |
| 2 | Benzene (%) | ≤0.3 | nought | |
| 3 | Toluene+ Ethylbenzene+ Xylenes (%) | ≤30 | 2 | |
| 4 | Free diisocyanate (TDI+HDI) (%) | ≤0.4 | nought | |
| 5 | halogenated halohydrocarbon (%) (Dichloromethane, 1.1 - dichloro ethane, 1 dichloro ethane, chloroform, 1.1.1- of three chlorine ethane, 1.1.2- three chlorine of ethane and carbon tetrachloride), (%) |
≤0.1
|
nought | |
| 6 | Soluble Heavy Metal (mg/kg) | Pb | ≤90 | nought |
| Cd | ≤75 | nought | ||
| Cr | ≤60 | nought | ||
| Hg | ≤60 | nought | ||
Company Brief Introduction:
We are first class one stop material supplier in China for high quality sports matrials,such as SPU course , running track , artificial grass, rubber particles and we are also engaging in the construction of sports venues.
We have two major production bases,one in Nanjing and the other in JiangMen,and the laying area of our materials is more than ten million square meters per year.
Our advantages (Why choose us?)
1. 1. Our products are odorless and non-toxic.
2. We have two main production bases and can make every kinds of SPU venues, running track, artificial grass, sports flooring construction and colloidal particles.
3. 3 3. We have more than 20 years' development and production history.
4. E 4. Exceed ten million squre meters every year in the world.
