94% High Efficiency 5.2KW Hybrid Solar Inverter Pure Sine Wave MPPT Off Grid

94% High Efficiency 5.2KW Hybrid Solar Inverter Pure Sine Wave MPPT Off Grid

Specification

Max. PV Array Open Circuit Voltage 500VDC
Max. PV Array Power 6000W
Operating Voltage MPPT Range 120-450VDC
Battery Overcharge Protection 63VDC
Max. Solar Charge Current 100A
Max. AC Charge Current 100A
Max. Charge Current 100A
Dimension 100 x 300x 440mm
Net Weight 10.2KG
Communication Interface USB/RS232
Humidity 5% to 95% Relative Humidity (Non-condensing)
Operating Temperature 0°C-55*C
Storage -15*C-60°C

INTRODUCTION:
The NKH series all in one solar system is the perfect go-to solution for off-grid, backup power for homes, small business, and it also delivers a value added, easy to install system that provides efficient power globally for every need. Combined with a 100A MPPT Solar Charge Controller, 80A AC charge Controller and Pure Sinewave Inverter. Efficiently works without battery.
