10 / 100M Active 16 Ports POE Ethernet Switch 48V POE Powered Switch
Price:
Negotiable
MOQ:
1 piece
Delivery Time:
1-3 work days
Brand:
NuFiber
Product Description
10 / 100M Active 16 Ports POE Ethernet Switch 48V POE Powered Switch
Features
- 16 x10/100Mbps PoE port;
- 2 x10/100Mbps Uplink port
- Whole power budget: 250W
- Support 250 meters long distance
- 6KV lightning protection
Specifications
| Product | Active 16+2 100Mbps PoE Switch |
| Model | NF-PSE5216F |
| Feature | Modular Design, Stardard Size |
| POE Port | 1 to 16 support IEEE802.3AF/AT Standard |
| Output Power | 15.4W/30W IEEE802.3af/at |
| Power Pin | Both 1/2+,3/6- and 4/5+7/8- |
| Whole Power | ≤250W (52V 2.3A) |
| POE Protocol | IEEE 802.3af/IEEE 802.3at |
| POE Type | End-span |
| Network Standard | IEEE 802.3, IEEE802.3u,802.3x,802.3af/at |
| Network Medium | 10/100BASE-TX:5 class and above non shielded twisted pair |
| Switch Capability | 2.0Gbps |
| Forwarding Mode | Store and forward |
| Forwarding Rate | 10BASE-T:14880PPS/port |
| MAC Address | MAC address table 2K |
| Port Function | Power priority mechanism, fast and forward, MAC automatic learning and aging |
| LED Indicator | LINK/ACT.100Mbps; POE Status Indicator; Power indicator;Extender |
| Working Environment | Working temperature:-10°-- 55°C |
Connection Diagram
Products Show
Product Show
Packing Information
Shipping Method
