Aisi Ss316 Ferrule Rope Mesh Diamond Woven Wire 80x80mm
Aisi Ss316 Diamond Ferrule Inox Stainless Steel Wire Cable Net Rope Mesh
Inox Stainless Steel Wire Cable Net Detailed Introductions:
Diamond Ferrule stainless steel wire cable net rope mesh is commonly used in bridge stair railing, large guardrail railing and building facade grid system. As a new product in the field of architectural decoration and protection, stainless steel rope net provides new fashion elements for modern architectural decoration and horticultural engineering, and is more and more favored by designers and customers all over the world. We can provide a wide range of grid products for countless applications. If you are not sure what to choose, please write to us for expert advice on the best grid structure for your application.
Inox Stainless Steel Wire Cable Net Specifications :
Inox Cable Net Details:
- Wire Diameter:1.2mm,1.6mm,2.0mm,2.4mm,3.2mm,4.0mm ,can be customized.
- Mesh Aperture:25x25mm,30x30mm,40x40mm,50x50mm,60x60mm,100x100mm,can be customized.
- Cable Structure:7x7,7x19
- Breaking load (lbs):270 to 1600
Mesh Type:Inter-woven type (Sleeveless Webnet) and Ferrule Type (Stainless steel ferrule)
Inox Stainless Steel Cable Net | |||||
| Item | Cable Diameter | Mesh Aperture | Normal Break | ||
| inch | mm | inch | mm | lbs | |
| YT-3212F | 1/8 | 3.2 | 4.75 x 4.75 | 120 x 120 | 1600 |
| YT-3210F | 1/8 | 3.2 | 4 x 4 | 102 x 102 | 1600 |
| YT-3290F | 1/8 | 3.2 | 3.55 x 3.55 | 90 x 90 | 1600 |
| YT-3276F | 1/8 | 3.2 | 3 x 3 | 76 x 76 | 1600 |
| YT-3250F | 3/32 | 2.4 | 2 x 2 | 51 x 51 | 1600 |
| YT-2410F | 3/32 | 2.4 | 4 x 4 | 102 x 102 | 920 |
| YT-2490F | 3/32 | 2.4 | 3.55 x 3.55 | 90 x 90 | 920 |
| YT-2476F | 3/32 | 2.4 | 3 x 3 | 76 x 76 | 920 |
| YT-2460F | 3/32 | 2.4 | 2.4 x 2.4 | 60 x 60 | 920 |
| YT-2450F | 3/32 | 2.4 | 2 x 2 | 51 x 51 | 920 |
| YT-2076F | 5/64 | 2.0 | 3 x 3 | 76 x 76 | 676 |
| YT-2060F | 5/64 | 2.0 | 2.4 x 2.4 | 60 x 60 | 676 |
| YT-2050F | 5/64 | 2.0 | 2 x 2 | 51 x 51 | 676 |
| YT-2038F | 5/64 | 2.0 | 1-1/2 x 1-1/2 | 38 x 38 | 676 |
| YT-1676F | 1/16 | 1.6 | 3 x 3 | 76 x 76 | 480 |
| YT-1650F | 1/16 | 1.6 | 2 x 2 | 51 x 51 | 480 |
| YT-1638F | 1/16 | 1.6 | 1-1/2 x 1-1/2 | 38 x 38 | 480 |
| YT-1630F | 1/16 | 1.6 | 1.2 x 1.2 | 30 x 30 | 480 |
| YT-1625F | 1/16 | 1.6 | 1 x 1 | 25.4 x 25.4 | 480 |
| YT-1238F | 3/64 | 1.2 | 1-1/2 x 1-1/2 | 38 x 38 | 270 |
| YT-1230F | 3/64 | 1.2 | 1.2 x 1.2 | 30 x 30 | 270 |
| YT-1225F | 3/64 | 1.2 | 1 x 1 | 25.4 x 25.4 | 270 |
Directions Of the Mesh Aperture :
There are two kinds of directions for the mesh Aperture,one is horizontal and the other is vertical.You can choose anyone you prefer.
Custom Colors:
Inox Stainless Steel Wire Cable Net Features :
The inox stainless steel wire cable net rope mesh used are woven of flexible wire ropes. Their advantages are numerous: they enable space-saving designs, offer the highest degree of transparency and visual airiness, guarantee safety for humans and animals and are convincing due to their low maintenance costs and longevity.
Inox Cable Net Application :
Inox stainless steel wire cable net rope mesh produced by Yuntong company is a dynamic and high-quality product, which is made of stainless steel AISI 316 material group: mesh W x H (variable from very tight to very wide), and the diameter of steel wire rope (1.2 mm, 1.5 mm, 1.6mm,2.0 mm,3.0mm and 4.0 mm) determines the function and beauty.
Packing And Delivery Details :
Plastic foam and Water-proof Cloth for inter packing ,Fumigated wooden cases for outer packing.
Delivery: by FedEx, DHL, UPS, TNT EMS, by air, Door-to Door or by sea.
Lead time:The order could be arranged within 24hours, lead time is between 7-15 days depending on the quantum of order.
As customer's requirements
Our Services:
Inox Cable Net is customizable to in widths and length to suit the place, where will you install the cable mesh.
Diagonal and irregular shapes can also be supplied.
Mesh Aperture is from 25mm x 25mm to 200mm x 200mm
Wire Diameter is from 1.2mm to 4.0mm.
