CE Single Channel Hormones Immunofluorescence Analyzer IFP-2000
Price:
$500-$800/set
MOQ:
1sets
Delivery Time:
5-10 days
Brand:
Diacegene
Product Description
Single channel Hormones analyzer Immunofluorescence Immunoassay Analyzer IFP-2000
Product Classification
The product is classified according to the classification catalogue of medical devices issued by the
State Food and drug administration, and belongs to the clinical test device (classification No.: 22-
04-03), and the management category is class II.
Instruments Model Description
The model of fluorescent immunoanalyzer is IFP-2000. where I is immunoassay, F is fluorescent ,
P is POCT(point of care testing) and 2000 is internal code.
Summary
Brief introduction of the Instruments
The fluorescent immunoanalyzer is a simple, small and portable automatic analyzer, which is
used to analyze the concentrations of various analytes in human samples quickly and
quantitatively.
Application Scope
Based on the principle of antigen antibody reaction and fluorescence immunoassay, the product is
used in combination with the matching reagent produced by our company for the quantitative
analysis of the substance to be tested in human samples.
Working principle
The detected substance in the test sample forms immune complex with the fluorescent labeled
antibody, and solidifies in the detection area and the quality control area respectively through the
capillary surge process. When the reagent card is inserted into the immunofluorescence detector,
the LED excitation light source irradiates the detection area and quality control area of the reagent
card, excites the solidified fluorescent immune complex, and the emitted light is collected and
converted into an electrical signal. The strength of the electrical signal is strictly related to the
number of fluorescent molecules. The detector automatically calculates the content of the
detected substance in the test sample according to the scanned signal.
Basic parameters of the Instruments
| Excitation light source | LED |
| Excitation spectrum | center wavelength λ 0 = 470nm |
| Receiving spectrum | center wavelength of λ 1 = 525nm |
| Software system | Chinese and English input method and self-defined intelligent management module are provided. |
| Release software version number | V1 |
| Interface | RS232 serial port, Ethernet port, USB interface |
| Printing | built-in thermal printer |
| Size | 200mm * 190mm * 180mm (L * W* H) |
| Weight | about 2kg |
| about 2kg | CV less than or equal to 15% |
| Stability | CV less than or equal to 8% |
| Ambient temperature | 10 ℃ ~ 30 ℃ (Note: the operating temperature of reagent shall be subject to the instruction) |
| Relative humidity | 10% ~ 70% |
| Host input | Host input |
| Power input | 40W |
| Power of the whole machine | less than 40W |
| Storage conditions | dry, clean and flat horizontal surface, avoiding direct sunlight, violent vibration and strong electromagnetic interference |
: ![]()
