230M/Min PLC Control Toilet Paper Rewinding Machine
Fully Automatic Toilet Paper Rewinding Machine,Toilet Paper Making Machine
XY-TQ-B Full Automatic Toilet Paper Rewinding Machine
Function and Features:
1. Automatic core feeding system, automatic log pusher after rewinding, then rewinding the new log again.
2. Automatic edge-trimming, core feeding, glue spraying and sealing synchronously in one time. Leaving 10-18mm tail, easy to rewind again, so reducing shortcut waste and save the cost.
3. Adopts international advanced PLC programmable controlling technique, man-machine interface operation, data set and parametric fault shows on touch screen.
4. Adopts 4 pieces high Precision spiral knives, low noise, clear perforation, adopt gearbox to have bigger range.
5. Three horizontal type back stands, pneumatic loading system, with wide driving flat belts; each jumbo roll can be adjusted independently.
6. Embossing Unit: adopt point to point embossing rollers, making the two layers match well, the paper is soft and has clear patterns
7. Adopt jogging switches for wearing the paper, easy and safe to operate.
Main Technical Parameters:
| Jumbo roll max width | 1750mm (Other size can be specified) |
| Jumbo roll diameter | Φ1200mm |
| Jumbo roll inner core diameter | 3inches(76.2mm) |
| Finish product diameter | Φ70-φ280mm |
| Finish product Inner core diameter | φ38-φ76mm |
| Perforation distance | 120-150mm |
| Production speed | 180-230m/min |
| PLC | INVT |
| Pneumatic system | 3HP Air Compressor, Minimum Pressure: 5kg/cm 2Pa(Provide by user) |
| Unwinding transmission | Variable stepless speed regulation |
| Rewinding Unit | With core or coreless |
