Industrial 1-1/8" (28mm) Bi-Metal Cutter | M42 Cobalt Construction | Extreme Heat Resistance for Continuous Heavy-Duty Metal Boring

1. Product Introduction: The Engineering Edge

Standard hole saws fail when they encounter the intense friction of stainless steel. Our 28mm M42 Cobalt Series is built differently. By fusing a premium 8% Cobalt edge to a high-flexibility alloy backer, we’ve created a tool that doesn't just cut—it dominates.

This 28mm (1-1/8") cutter is specifically optimized for 1-inch electrical conduit and industrial pipe fittings. Whether you are working on an offshore oil rig, a commercial kitchen installation, or heavy automotive maintenance, the M42 metallurgy ensures your first cut is as sharp as your hundredth.

2. Differentiated Technical Specs

3. Why This Tool is Different (USP)

• The 8% Cobalt Advantage (Red Hardness): Regular M3 steel loses its hardness at 600°F. Our M42 Cobalt teeth maintain structural integrity up to 1200°F. This "Red Hardness" is critical for 28mm diameters where peripheral speed generates high localized heat.

• Non-Harmonic Variable Pitch (4/6 TPI): Standard teeth create vibration (chatter). Our 4/6 TPI variable design uses irregular tooth heights and gullet depths to break harmonic resonance. This means 50% less vibration and a mirror-smooth hole edge.

• Heavy-Duty Deep-Throat Design: With a 38mm (1-1/2") cutting depth, this saw handles double-layer drywall, thick timber joists, and heavy-gauge metal plates in a single pass.

• Rapid-Eject Side Windows: We’ve oversized the lateral slots to ensure that metal "slugs" don't get vacuum-sealed inside. A quick flick of a screwdriver through the Speed-Slot pops the core out in seconds.

4. Target Applications: Beyond Wood

• Stainless Steel Fabrication: Sinks, control boxes, and 304/316 piping.

• Electrical MRO: Precision holes for 1" conduit fittings in galvanized steel.

• Commercial Plumbing: Installing copper and PVC lines through heavy flooring.

• Automotive: Drilling through high-tensile truck frames and aluminum panels.

5. Pro-FAQ: Addressing High-End Concerns

Q: Will the teeth strip if I hit a knot or a metal stud?

A: No. Thanks to the Electron-Beam Welding, the HSS edge is essentially one with the spring-steel body. It is designed to flex and absorb shock rather than snap.

Q: Can I use this for dry cutting in metal?

A: While M42 can handle higher heat than M3, we always recommend a drop of cutting oil for 28mm holes in metal. This extends tool life by an additional 40% and keeps the chips from sticking to the teeth.

Q: Does it fit my standard 1/2" chuck?

A: Yes. This 28mm saw uses a standard arbor interface. We recommend a 7/16" Hex Arbor for maximum torque transfer without slipping.
