Fuel Injector 2488244 2872544 2872289 2872284 4955080 for Stenia DC13 DC16 Engine
Price:
$60-$100
MOQ:
1
Delivery Time:
3-5 work days
Brand:
CUMMINS
Product Description
Fuel Injector 2488244 2872544 2872289 2872284 4955080 for Stenia DC13 DC16 Engine
Product Description:
| Number |
2488244 |
| OEM NO |
2872289 |
| AppliC-A-Tion | C-UMMINS INJECTOR |
| Payment Term | T/T, L/C, Western |
Table 1: Basic Parameters
| Parameter | Details |
| Part No. | 2488244 |
| Engine Series | C-ummins ISZ13, QSZ13, XPI2400 |
| Fit For | Scania DC1305, DC1307, DC16 engines |
| Type | Electronic High-Pressure Common Rail Injector (XPI) |
| Control | Solenoid, Ultra-High Pressure Direct Injection |
| Net Weight | 1.28 kg |
| Gross Weight | 1.30 kg |
| Dimensions | 260mm × 60mm × 60mm |
Table 2: Performance Specifications
| Parameter | Details |
| Fuel System | XPI Ultra-High Pressure Common Rail |
| Max Injection Pressure | 2400 bar |
| Nozzle | Multi-Hole Precision Atomization |
| Control | Engine ECM Electronic Pulse Control |
| Operating Voltage | 24V (Commercial Vehicle Standard) |
| Seal Material | High Temp Fluororubber, Copper Gasket |
| Fuel Standard | Euro V / China V Diesel |
| Temp Range | -40℃ to +120℃ |
Table 3: Application & Installation
| Parameter | Details |
| Engine Fit | C-ummins ISZ13 (13L Inline 6-Cylinder) |
| Bore × Stroke | 130mm × 163mm |
| Power Range | 430–560 HP (412kW) |
| Torque Range | 2000–2500 N·m |
| Install Torque | Standard: 85±5 N·m |
| Gasket | S4327277 (Copper, Single Use) |
| Install Notes | Dust-free, replace seals, clean fuel passages |
| ECU Match | Original C-ummins Electronic Control Module |
Table 4: Quality & Warranty
| Parameter | Details |
| Grade | New Original / Remanufactured |
| Factory Test | 100% Test: Electric, Leakage, Flow, Durability |
| Warranty | New: 12 Months; Reman: 6 Months |
| Standard | ISO 9001, C-ummins Standard |
| Packing | Single Box (28×8×8cm) + Anti-Rust |
| MOQ | 1 PC |
| Failure Signs | Leak, Poor Atomization, Hard Start, Black Smoke |
| Void Conditions | Bad Fuel, Overpressure, Overtemp, Disassembly |
Why choose us?
1.The product has undergone a rigorous testing process, and we provide high-quality products.
2.We have our own professional forwarding agent: Fast delivery, serve good.
3.Our feedback: You always can get our feedback within 24 hours.
4.After sending, we will track the products for you once every two days, until you get the products.
PRODUCTS PICTURE:
