Wholesale High-performance Fuel Components Fuel Injector 3083863 3087807 3411766 3087558F 4902924 3411764 3411767 for M11 Engine
Price:
$60-$100
MOQ:
1
Delivery Time:
3-5 work days
Brand:
CUMMINS
Product Description
Wholesale High-performance Fuel Components Fuel Injector 3083863 3087807 3411766 3087558F 4902924 3411764 3411767 for M11 Engine
Product Description:
| Number |
3083863 |
| OEM NO |
3087807 |
| AppliC-A-Tion | C-UMMINS INJECTOR |
| Payment Term | T/T, L/C, Western |
Table 1: Basic Parameters
| Parameter | Details |
| Part No. | 3083863 |
| Engine Series | C-ummins M11, ISM11, QSM11 |
| Type | Mechanical PT Injector (with STC Timing) |
| Structure | Plunger-type, Mechanical, Tappet-driven |
| Net Weight | 1.35 kg |
| Dimensions | 185mm × 50mm × 50mm |
| Material | Body: Alloy Cast Iron; Parts: Hardened High-Speed Steel |
| Fuel System | PT (Pressure-Time) System |
Table 2: Performance Specifications
| Parameter | Details |
| Control | Cam-driven, STC (Step Timing Control) |
| Opening Pressure | 1800–2000 PSI (124–138 bar) |
| Flow Rate | 280–300 cc/min @ 100 PSI |
| Nozzle Type | Pintle / Multi-Hole (Spray Angle 150°) |
| Fuel | China III / Below Diesel, 0# / -10# Diesel |
| Temp Range | -30℃ to +110℃ |
| Seals | Fluororubber O-rings, Copper Gaskets |
| Actuation | Engine Camshaft & Tappet Mechanism |
Table 3: Application & Installation
| Parameter | Details |
| Engine Fit | C-ummins M11 (10.8L Inline 6-Cylinder) |
| Bore × Stroke | 125mm × 147mm |
| Power Range | 280–450 HP |
| Torque Range | 1350–1700 N·m |
| Install Torque | 55–65 N·m |
| Gasket | 3077265 (Copper, Single Use) |
| Install Notes | Clean fuel passages, replace seals, calibrate lift |
| Applications | Heavy-duty Trucks, Construction, Gen-Sets, Marine |
Table 4: Quality & Warranty
| Parameter | Details |
| Grade | New Original / OEM Remanufactured |
| Factory Test | Flow Test, Leak Test, Opening Pressure Calibration |
| Warranty | New: 12 Months; Reman: 6 Months |
| Standard | C-ummins Original Standard, ISO 9001 |
| Packing | Single Box + Anti-Rust Oil + Shock-Proof |
| MOQ | 1 PC |
| Common Failures | Poor Atomization, Dripping, Hard Start, Black Smoke |
| Void Conditions | Contaminated Fuel, Overpressure, Disassembly |
Why choose us?
1.The product models are complete, thousands of models of products can meet your needs.
2.We have our own professional forwarding agent: Fast delivery, serve good.
3.Our feedback: You always can get our feedback within 24 hours.
4.After sending, we will track the products for you once every two days, until you get the products.
PRODUCTS PICTURE:
