Common Rail Fuel Injector Assembly 3087648 3079946 3079947 Truck Engine Parts
Price:
$60-$100
MOQ:
1
Delivery Time:
3-5 work days
Brand:
CUMMINS
Product Description
Common Rail Fuel Injector Assembly 3087648 3079946 3079947 Truck Engine Parts
Product Description:
| Number |
3079946 |
| OEM NO |
3087648 |
| AppliC-A-Tion | C-UMMINS INJECTOR |
| Payment Term | T/T, L/C, Western |
Table 1: Basic Parameters
| Parameter | Details |
| Part No. | 3079946 |
| Engine Series | C-ummins M11, ISM11, QSM11 (PT Fuel System) |
| Type | Mechanical PT Injector (PTD, with STC Timing) |
| Structure | Plunger-type, Cam-driven, Cylinder, Flangeless |
| Net Weight | 1.42 kg |
| Dimensions | 195mm × 55mm × 55mm |
| Material | Body: Alloy Cast Iron; Parts: Hardened High-Speed Steel |
Table 2: Performance Specifications
| Parameter | Details |
| Fuel System | PT (Pressure-Time) Low-Pressure System |
| Opening Pressure | 125–135 bar (1800–1960 PSI) |
| Flow Rate | 290–305 cc/min @ 100 PSI |
| Nozzle | 8-Hole × 0.20mm, Spray Angle 150° |
| Timing Control | STC (Step Timing Control) Mechanical |
| Fuel Standard | China III / Below Diesel, 0# / -10# / -20# |
| Temp Range | -30℃ to +110℃ |
| Seals | 2× Fluororubber O-rings, Copper Gasket |
| Actuation | Camshaft, Tappet & Pushrod Mechanism |
Table 3: Application & Installation
| Parameter | Details |
| Engine Fit | C-ummins M11 (10.8L Inline 6-Cyl, Turbocharged Aftercooled) |
| Bore × Stroke | 125mm × 147mm |
| Power Range | 300–420 HP |
| Torque Range | 1450–1650 N·m |
| Install Torque | Retaining Nut: 58–62 N·m |
| Gasket | 3077265 (Copper, Single-Use Only) |
| Install Notes | Clean Fuel Passages, Replace Seals, Calibrate Plunger Lift |
| Applications | Heavy Trucks, Construction, Gen-Sets, Marine |
Table 4: Quality & Warranty
| Parameter | Details |
| Grade | New Original / OEM Remanufactured |
| Factory Test | 100% Flow, Pressure, Leakage & Atomization Test |
| Warranty | New: 12 Months; Reman: 6 Months |
| Standard | C-ummins Original, ISO 9001:2015 |
| Packing | Single Box, Anti-Rust Oil, Shock-Proof Foam |
| MOQ | 1 PC |
| Common Failures | Poor Atomization, Dripping, Hard Start, Black Smoke |
| Void Conditions | Contaminated Fuel, Overpressure, Unauthorized Disassembly |
Why choose us?
1.Super Value - Our rich experience help you increase profit on cost advantage.
2.We have our own professional forwarding agent: Fast delivery, serve good.
3.Our feedback: You always can get our feedback within 24 hours.
4.After sending, we will track the products for you once every two days, until you get the products.
PRODUCTS PICTURE:
