Remanufactured N14 Diesel Engine Cellet Injector 3080766 3411767
Price:
$60-$100
MOQ:
1
Delivery Time:
3-5 work days
Brand:
CUMMINS
Product Description
Remanufactured N14 Diesel Engine Cellet Injector 3080766 3411767
Product Description:
| Number |
3080766 |
| OEM NO |
3411767 |
| AppliC-A-Tion | C-UMMINS INJECTOR |
| Payment Term | T/T, L/C, Western |
Table 1: Basic Parameters
| Parameter | Details |
| Part No. | 3080766 |
| Engine Series | C-ummins N14 (14L) Celect, Celect Plus E-Controlled Engines |
| Type | Electronic Unit Injector (EUI), Celect Electronic Control |
| Structure | Integrated Solenoid Actuator, Plunger Boost, Top Outlet, Side Electrical Connector |
| Net Weight | 1.68 kg (3.71 lbs) |
| Dimensions | 254mm × 55mm × 55mm |
| Material | Body: Forged Steel; Components: Hardened Alloy; Solenoid: High Permeability Stainless Steel |
Table 2: Performance Specifications
| Parameter | Details |
| Control | ECM Electronic Control (12V Solenoid), Closed-Loop Timing & Flow |
| Opening Pressure | 240–260 bar (3480–3770 PSI) |
| Flow Rate | 380–400 cc/min @ 100 PSI |
| Nozzle | 9-Hole × 0.22mm, Spray Angle 145° |
| Fuel System | Low-Pressure PT Feed + Unit Injector High-Pressure Generation |
| Fuel | China II/III Diesel, 0# / -10# / -20# |
| Temp Range | -40℃ to +120℃ |
| Seals | 3× Fluororubber O-Rings, Copper Gasket, High-Temp Dust Seal |
| Electrical | 2-Pin Deutsch Connector, IP67 Protection |
Table 3: Application & Installation
| Parameter | Details |
| Engine Fit | C-ummins N14 (14.0L Inline 6-Cyl, Turbocharged & Aftercooled) |
| Bore × Stroke | 139mm × 152mm |
| Power Range | 435–525 HP |
| Torque Range | 1900–2300 N·m |
| Install Torque | Mounting Bolts: 65–75 N·m |
| Gasket | 3069169 (Copper, Single-Use Only) |
| Install Notes | Deep Clean Fuel Passages, Replace All Seals, ECM Recalibration |
| Applications | Heavy-Duty Trucks, Construction, Mining, Marine, Gen-Sets |
Table 4: Quality & Warranty
| Parameter | Details |
| Grade | New Original / OEM Remanufactured (RX/R Suffix) |
| Factory Test | 100% Flow, Pressure, Response, Atomization, Leakage & Durability Test |
| Warranty | New: 12 Months; Reman: 6–12 Months |
| Standard | C-ummins Celect Original, ISO 9001:2015 |
| Packing | Single Box, Anti-Rust Oil, Shock-Proof Foam, Anti-Static Bag |
| MOQ | 1 PC |
| Common Failures | Slow Response, Poor Atomization, Dripping, Black Smoke, Low Power, Rough Idle |
| Void Conditions | Bad Fuel, Contamination, Overpressure, Water Damage, Disassembly, Uncalibrated Programming |
Why choose us?
1.The product has undergone a rigorous testing process, and we provide high-quality products.
2.We have our own professional forwarding agent: Fast delivery, serve good.
3.Our feedback: You always can get our feedback within 24 hours.
4.After sending, we will track the products for you once every two days, until you get the products.
PRODUCTS PICTURE:
