GENUINE NEW HPI Diesel Engine Fuel Injector for QSK23 QSK60 4902827 4076533 4077076 4062090 4326780 4928346 4010029 3408282
GENUINE NEW HPI Diesel Engine Fuel Injector for QSK23 QSK60 4902827 4076533 4077076 4062090 4326780 4928346 4010029 3408282
| Number |
4077076 |
| OEM NO |
4928346 |
| AppliC-A-Tion | C-UMMINS INJECTOR |
| Payment Term | T/T, L/C, Western |
Table 1: Basic Parameters
| Parameter | Details |
| Part No. | 4077076 |
| Engine Series | C-ummins QSK60 (V16 Heavy-Duty Engine) |
| Type | High-Pressure Common Rail Injector (HPI System) |
| Control Type | Solenoid Actuated, ECM Closed-Loop Control |
| Structure | Long-Stem, Top Inlet, Bottom Outlet, Integrated Solenoid |
| Net Weight | 2.15 kg |
| Dimensions | 315mm × 62mm × 62mm |
| Material | Forged Steel, Precision Hardened Alloy Components |
Table 2: Performance Specifications
| Parameter | Details |
| Fuel System | C-ummins HPI High-Pressure Common Rail |
| System Operating Pressure | 1800–2400 bar |
| Nozzle Opening Pressure | 340–360 bar |
| Standard Flow Rate | 530–550 cc/min @ 100 PSI |
| Nozzle Configuration | 10-Hole × 0.24mm, Spray Angle 150° |
| Operating Voltage | 24V DC |
| Electrical Connector | 2-Pin Deutsch, IP67 |
| Response Time | ≤0.28 ms |
| Fuel Standard | 0#/-10#/-20# Diesel, China III/IV, Euro III |
| Temperature Range | -40℃ to +135℃ |
Table 3: Application & Installation
| Parameter | Details |
| Fit Engine | C-ummins QSK60 (V16 60L) |
| Bore × Stroke | 159 mm × 190 mm |
| Power Range | 1500–2500 HP |
| Torque Range | 6500–9500 N·m |
| Installation Torque | 90–100 N·m |
| Gasket | 4099395 (Copper, Single-Use Only) |
| Installation Notes | Clean fuel passages, replace seals, ECM calibration |
| Applications | Mining Trucks, Oilfield Units, Marine Main Engines, Gen-Sets |
Table 4: Quality & Warranty
| Parameter | Details |
| Product Grade | New Original / OEM Remanufactured |
| Factory Test | 100% Flow, Pressure, Leakage, Atomization, Response & Durability Test |
| Warranty | New: 12–24 Months; Reman: 6–12 Months |
| Standard | C-ummins QSK Original, ISO 9001, TS16949 |
| Packing | Single Box, Anti-Rust Oil, Shock-Proof Foam, Anti-Static Bag |
| MOQ | 1 PC |
| Common Failures | Poor atomization, leakage, black smoke, low power, rough idle |
| Void Conditions | Contaminated fuel, water damage, overpressure, disassembly, uncalibrated use |
C-ummins QSK60 Series injectors are designed for 60.2L V16 large-displacement QSK60 electronic control engines, as core components of the high-pressure common rail system, adopting C-ummins HPI ultra-high pressure injection technology and ECM electronic closed-loop control. Integrating high-permeability solenoid valves and hard alloy precision parts, covering core models such as 4088428 and 2881089, they fit 1500-2500 HP, widely used in extreme heavy-duty scenarios.
Relying on 24V solenoid valves to achieve millisecond-level precise control, these injectors have uniform and delicate atomization, which can effectively optimize fuel combustion efficiency, reduce carbon deposits and exhaust emissions, meeting Tier3/4 and Euro V emission standards. Complying with C-ummins original standards and relevant quality systems, fully tested before leaving the factory, they are easy to install and maintain for stable long-term operation.
Why choose us?
1.We are very glad that customer give us some suggestion for price and products.
2.We have our own professional forwarding agent: Fast delivery, serve good.
3.Our feedback: You always can get our feedback within 24 hours.
4.After sending, we will track the products for you once every two days, until you get the products.
PRODUCTS PICTURE:
