Anti-yellowing Polyester Resin 93/7 TGIC Cure NH3306 for Texture Powder Coating with Excellent Impact Resistance

◇ Applications:

NH3306 is saturated carboxyl polyester resin for applications of polyester/TGIC powder coating system. For the field of high-end powder coatings, Kinte launched high-end UV absorbers, which have very high thermal stability, light stability and low mobility, and are the best choice for customers in many industries.

◇ Basic features:

Good leveling

Excellent anti-yellowing

Excellent storage stability

Good weathering resistance

Suitable for the powder coatings with deep or bright color.

◇ Specifications:

Appearance White or light yellow transparent flakes

Color(50%DMF): max:2

Acid number(mgKOH/g): 31～36

Softening point(℃): 104～114

Glass transition temp.(℃): ～69

Melting viscosity(200℃, cone/plate, mPa·s): 9000±800

Reactivity at 180℃(s, 7% TGIC): 170±30

◇ Recommend Formulation:NH3306—TGIC

◇ Extrusion Condition:

Two-screw extruder

Zone I: 90～110℃ Zone II: 110～120℃

Speed of revolution: 500～1200rpm

Fineness of powder: ＜100μm

◇ Application Condition:

Electrostatic spraying with: 40～70KV

Coating film thickness: 50～100μm

Degreased cold-rolled steel 0.5mm

◇ Curing Requirement: 200℃×10min

◇ Film Properties:

Gel time(180℃,sec) 200~300

Horizontal flow(180℃,mm): 22-26

Gloss(60°): ≥85%

Bending(φ1mm): pass

Adhesive(1mm,grade): 0

Pencil hardness: ≥1H

Impact (50cm): pass

◇ Packaging:

PE bags, N.W. 25KG±0.1KG / bag

Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)
