HAA Polyester Resin NH6358 for Powder Coating required thicker film and Pinhole Free

◇ Applications:

NH-6358 is a saturated carboxyl polyester resin designed for 93:7 Primid XL 552 powder coating.

◇ Basic features:

Marvelous weatherablity

Outstanding mechanical properties

Fine anti-yellowing

Pinhole free in thicker films

Good storage stability.

◇ Specifications:

Appearance: pale yellow flake

Color(50%DMF): max:2

Acid number(mgKOH/g): 30～35

Softening point(℃): 100～110

Glass transition temp.( ℃): ～60

Melting viscosity(200℃, cone/plate, mPa·s): 3800±500

Reactivity at 180℃(s, 5% T-105): 180±40

◇ Recommend Formulation:NH-6358

◇ Extrusion Condition:

Two-screw extruder

Zone I: 90～110℃ Zone II: 110～120℃

Speed of revolution: 500～1200rpm

Fineness of powder: ＜100μm

◇ Application Condition:

Available for electrostatic spraying with: 40～70KV

Coating film thickness: 50～100μm

Degreased cold-rolled steel 0.5mm

◇ Curing Requirement: 190℃×10min.

◇ Film Properties:

Gel time(180℃,sec) 120~220

Flow(180℃,mm) 23~27

Gloss(60°): ≥85%

Bending(φ1mm): pass

Adhesive(1mm,grade): 0

Pencil hardness: 1H

Impact(50cm): pass

Storage test(40℃,24hr): good

Remarks:

All the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)

The consistency and stability of products are guaranteed through rigorous quality inspection
