Dry Blended Polyester Resin NH9001&NH9508 for Super Durable Matte Powder Coating

With the increasing development of national economy and the continuous improvement of people's living standards, the requirements for decoration, weather resistance, chemical resistance, water resistance and stain resistance of coatings are higher and higher, so the demand for super weather resistant powder coatings is increasing day by day.

As a long-standing manufacturer of polyester resin for powder coatings, Kinte has decades of research experience in super durable matte powder coatings.

◇ Applications:

NH9001/NH9508 are saturated carboxyl polyester resins for low gloss polyester/TGIC powder coatings by a dry blending procedure.

◇ Basic features:

Excellent leveling

Excellent weathering resistance

Excellent mechanical properties

Good chemical resistance

Good storage stability

◇ Specifications:

                                                     NH9001                          NH9508

Appearance:                            pale yellow flake             pale yellow flake

Color(50%DMF):                                ≤3                                     ≤2

Acid number(mgKOH/g):                46～54                             19～25

Softening point(℃):                       103～113                         103～113

Glass transition temp.( ℃):                  ~65                                  ~63

Melting viscosity:                            5100±800                          5000±500

(200℃, cone/plate, mPa·s)

Reactivity at 180℃(s, TGIC):             50±25                              330±60

◇ Recommend Formulation:

◇ Extrusion Condition:

Two-screw extruder

Zone I: 90～110℃ Zone II: 110～120℃

Speed of revolution: 500～1200rpm

Fineness of powder: ＜100μm

Blend I and II in the weight ratio of 1:1 before grinding.

◇ Application Condition:

Electrostatic spraying with: 40～70KV

Coating film thickness: 50～70μm

Degreased cold-rolled steel 0.5mm

◇ Curing Requirement: 200℃×10min

◇ Film Properties:

Gloss(60°): ≤40%

Bending(φ1mm): Pass

Adhesive(1mm,grade): 0

Pencil hardness: ≥2H

Direct Impact (50cm): pass

◇ Packaging:

PE bags, N.W. 25KG±0.1KG / bag

Remarks:all the polyester resins could be customizes to Non-tin (A) ,anti gas burners(G),tribo gun(T) and anti-blooming(F)

Kinte have repeatedly introduced advanced technology in the industry, with advanced production equipment, testing instruments and high-quality technical talents;We will meet the needs of new and old customers with excellent quality and perfect service.
