0.2 Class CT PT Test Equipment Electromagnetic Type VT
CT/PT Ratio & Polarity Tester MCVT-RP01
Technical Index
| Ratio test range | 5A/5A-25000A/5A, 5A/1A-5000A/1A |
| Test object type | various CT and all electromagnetic type VT |
| Test accuracy | 0.2% |
| Dimension | 280*230*100mm |
| Weight | 3kGS |
Features
1) Adopting voltage method for measurement, small size and light weight
2) Voltage waveform generated by microprocessor, high purity and without grid interference
3) Adopting constant voltage source and stable reading
4) Suitable for the test of all current transformer up to 25000A, and of all electromagnetic type voltag
transformer
5) Directly showing ratio test value and polarity status
6) Electronic method for testing of polarity
7) Simple and easy operation
8) English or other language interface available according to client requirement
9) With battery
the below indication show on screen, that means the battery power is not enough but need to give charging
Technical service
Much experienced technical team will provide strong technical support for your market development. We can provide support on customization, maintenance, device design, construction scheme, design optimization, and product development.
Quality control
We have professional quality control team. Our quality control covers materials, production procedure, finished product inspection, final inspection before loading, inspection report.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
