12 Core OM3 MPO to LC Fanout Fiber Optic Cable LSZH CPR Certified
Price:
0.01
MOQ:
1
Delivery Time:
2-15 working days, depends on quantity
Brand:
Takfly / OEM
Product Description
CPR Dca Certified 12 Cores Optical Fiber Cable Om3 MPO to LC Fanout Cable
Product Attributes
| Attribute | Value |
|---|---|
| Model NO. | MPO to LC Fanout Cable Fiber Optic Cable |
| Connection Structure | MPO-LC |
| Material Shape | Round Wire |
| Allowed Lateral Pressure | 100(N/100mm) |
| Allowed Tensile Strength | <100N |
| Core | Multicore |
| Brand | OEM |
| Sheath Material | LSZH |
| Fiber Length | 1m, 2m, 3m, 5m or Customized |
| Fiber Type | Om3 |
| Business Type | Manufacturer |
| Connector Brand | Senko, Us Conec or Neutral |
| Customized | Available |
| Connector Type | MPO/MTP-LC |
| Cores | 12/24/48 Cores |
| Head Face | Upc |
| Jacket Material | PVC, LSZH |
| Insertion Loss | ≤0.75dB(Standard Loss); Low Loss≤ 0.35dB |
| Transport Package | Plastic Bag and Carton |
| Specification | MPO-LC 12 Cores Fiber Optic Patchcord |
| Trademark | TAKFLY/OEM/DF |
| Origin | China |
| HS Code | 8544700000 |
| Production Capacity | 50, 0000/Week |
Product Description
This 12Cores MPO Fiber Optic Patch Cable assembly facilitates rapid deployment of high density backbone cabling in data centers, 5G mobile communication base stations and other high-fiber environments, reducing network installation or reconfiguration time and cost. They are used to interconnect modules, panels or ruggedized MTP/MPO Fanouts.
Key Features
- High Density: Multifiber connector and compact dimension of ruggedized micro cable ease space in costly data center environments
- Rapid Deployment: Factory terminated modular system saves installation and reconfiguration time during moves, adds and changes
- Reliability: 100% tested - combination of high quality components and manufacturing quality control guarantees product to the highest standards
- Next Generation Network Proof: Emerging high speed protocols use MTP/MPO interface - your cabling infrastructure remains unchanged
- Compact design with up to 4,8,12,24 fibers
Certifications
CE, ROHS, REACH, CPR, ISO9001 and ISO14001.
Technical Specifications
| Item | LC,SC,ST,FC... | MPO |
|---|---|---|
| End face type | UPC and APC | PC and APC |
| Fiber type | SM(G652,G655,G657);MM(OM1-OM5) | |
| Core number | 12,24 | |
| Cable Diameter | 0.9,2.0,3.0 | Mini Round cable:Max4.5mm; Ribbon cable:Max3.0*5.0mm |
| Insertion loss(dB) | ≤ 0.3 | Standard:≤0.35/0.75(Typical/Max) Low Loss:≤0.2/0.35(Typical/Max) |
| Return loss(Min) | UPC SM:50dB APC SM:60 dB PC MM:35 dB | SM: APC:60 PC:50 | MM: APC:30 PC:25 |
| Test Wavelength(nm) | SM:1310/1550 MM:850/1300 | |
| Repeatability | ≤ 0.1dB | |
| Durability | ≤ 0.2dB | |
| Interchangeability | ≤ 0.2dB | |
| Operating Temperature | -20ºC~70ºC | |
| Storage Temperature | -40ºC~80ºC | |
| Outer Sheath Material | PVC, LSZH,TPU | |
| Bending radius(Static/Dynamic) | 10D/20D | |
| Length | Customized | |
Ordering Options
| Fiber Type | Cable Type | Connector | Boot Size | Boot Color | Polishing Type | Length |
|---|---|---|---|---|---|---|
| SM: 9/125μm | Simplex(2-fiber) | Male or Female | 2.0mm | Black | PC or APC | Customized |
| MM: 50/125μm | Duplex | 3.0mm | ||||
| MM: 62.5/125μm | Ribbon | Ribbon | ||||
| MM: OM3 | Breakout |
Applications
- Telecommunication Networks
- Computer networks
- CATV networks
- FTTx Termination
- Gigabit Ethernet
Why Choose TAKFLY - Manufacturer Advantages
- More than 25 years manufacturing experience in Fiber optic products - one stop purchasing
- More than 450 assembly workers with 3 years experience
- More than 26 R&D Engineers, OEM, ODM customer designs are also welcomed
- 16 Sets Germany imported Injection Machine and More than 10 Cable Production Lines
- More than 30 sets of Testing Machines: OTDR,3D, VFL, IL&RL test instrument; tension strength tester, Crush Resistance tester, Power meter tester, light checker, etc.
- Factory directly supply, Quality and Delivery are under control
- Exhibition: OFC, ECOC, CommunicAsia, NETCOM, AFRICACOM, SVIAZ ICT, CommunicIndonesia, Global Source Electronic Exhibition, etc.
- After-sales Services: Available for 24 hours
- Certified with ISO9001 & ISO14001, all products meet CE, ROHS, REACH standard, CPR and Anatel certificate available upon request
- Main customers: Fibertronics, Corning, R&M, Amphenol, SENKO, Telefonica, Orange, Movistar, Vodafone, Singtel, etc.
Quality Control Process
- Spot check the raw material incoming inspection before production
- Fully check after every individual process finished
- Fully check production half done
- Fully check the finished products before packing
- Spot check before shipping
Delivery & Shipping
Delivery Time:
- Samples: 1-3 working days
- Mass Production Order: 3-7 working days
- Packaging: Plastic Bag, Carton and Pallet available according to request
Shipping Methods:
- DHL, UPS, FEDEX, TNT, EMS (3-5 working days) with tracking status reporting
- By Sea or By Air using your preferred forwarder or our cooperated one
Payment Terms
T/T, Paypal, Western Union and L/C are available.
Note: Price can be negotiated for large quantity orders.
With more than 25 years of sales and shipping experience in optical fiber products, we have helped more than 127 customers expand their business. We can provide professional guidance to help you save time and money while increasing your sales.
Contact us today for more information or to request a quote.
Contact us today for more information or to request a quote.
