Takfly FC-FC Duplex Fiber Patch Cord 2m 62.5/125um 3.0mm

Name: Takfly FC-FC Duplex Fiber Patch Cord 2m 62.5/125um 3.0mm
Brand: TAKFLY COMMUNICATIONS CO., LTD.

Price Negotiable

Price: 0.6

MOQ: 1

Delivery Time: 2-15 working days, depends on quantity

Brand: Takfly

Product Description

FC/PC-FC/PC Duplex 62.5/125um 3.0mm 2m Fiber Patch Cord

Optical Fiber Connector provides quick and easy fiber termination in the field. Available for 900 micron applications, allowing installers to terminate and connect in minutes at equipment and fiber patch panels. Our quick connector system eliminates the need for epoxy, adhesives, or costly curing ovens. All key steps are completed in the factory to ensure excellent connections. High quality at low cost through direct sourcing.

Key Features

Low insertion loss
High return loss (low reflection at interface)
Easy installation
Cost-effective
Reliable performance
Low environmental sensitivity
User-friendly design

Applications

CATV systems
Active device termination
Telecommunication networks
Metro networks
Local Area Networks (LANs)
Data processing networks
Test equipment
Premise installation
Wide Area Networks (WANs)

Specifications

	Singlemode (UPC)	Singlemode (APC)	Multimode
Insertion loss	≤ 0.2db	≤ 0.2db	≤ 0.25db
Return loss	≥55db	≥65db	≥30db
Durability	≤ 0.1db typical change, 1000 times mating
Operating Temperature	-45 to +85 degree

Ferrule Hole Sizes

Singlemode (UPC/APC)	Multimode
125.0+1/-0um, Concentricity: ≤1.0um	125.0um, Concentricity: ≤3.0um
125.3+1/-0um, Concentricity: ≤1.0um
125.5+1/-0um, Concentricity: ≤1.0um
126.0+1/-0um, Concentricity: ≤1.0um

Product List

Item	Connector Description	Item	Connector Description
	PC/UPC/APC		PC/UPC/APC
Connector Singlemode 9/125	ST	Connector Multimode (50/125 or 62.5/125)	ST
	SC		SC
	FC		FC
	LC		LC
	MU		MU
	MTRJ(female)		MTRJ(female)
	MTRJ(male)		MTRJ(male)
	DIN		E2000
	E2000
