GYTA Outdoor Fiber Optic Cable Jelly Gel Waterproof Filling Metallic G652D G657A1 G675A2

GYTA Jelly Gel Waterproof Filling Metallic G652d G657a1 G675a2

Product description:
GYTS/A ,the fibers are positioned in the loose tube made of high modulus polyester.each loose tube is stranded arounded a steel wire located in the center of core as a metallic strength member ,the cable core is filled with water resistance
compound.corrugated steel tape is laminated at both side and bonded to PE outer jacket .

Characteristics:
1. The loose tube filled with moisture-proof and water blocking compound ensue impermeable
2. Excellent mechanical and enviromental performance
3. Metal strength member provides excellent strain performance
4. Longitudinal corrugated steel tape is laminated at both side and bonded to PE outer jacket, It ensures not only radial
moisture-proof but also reinforces the crush resistance of fiber optical cable

Application:
Long-distance telecom, LAN in high-voltage area or access to telecom network

GYTA cable is suitable for aerial or duct installation
Especially for power transmission system. excessive thunder areas and high electromagnetic interference.
Recommended layings methods

Advantages:
1. Low dispersion and attenuation.
2. Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental characteristics.
3. Anti-electromagnetism ability.
4. Small cable diameter, light cable weight, easily to install.

Performance :
Max attenuation : 0.35dB @ 1310nm and 0.21dB/Km @1550nm Fiber : G652D
Installation: Suitable for aerial or duct
Application: Apply to Long distance communication system, Local area network system and Subscriber network system
Operating temperature : -40°C~+70°C
Permisson bent radius Static : 10 times O.D.
Dynamic : 20 times O.D.

Technical Parameters:


Package and Delivery
