W01-M58-6040 Firestone Air Bags Replacement Single Convoluted Airstroke Actuators Style 19-.75

GUOMAT No.

Reference

Description

1B4060

Contitech : FS 40-6 1/8 M8

Phoenix : SP1B04

Weforma: WBE100-E1

G1/8 air inlet, M8 blind nuts, 20mm screw center disrance

145mm Max. rubber bellow diameter, 50mm Min. height, 110 Max. height

1B7070

Contitech: FS 70-7

Phoenix : SP 1 B 05
Bosch : 822419002
Festo : EB-165-65
Weforma : WBE 200-E1

G1/4 air inlet, M8 blind nuts, 44.5mm screw center disrance

165mm Max. rubber bellow diameter, 50mm Min. height, 115 Max. height

1B7731

Firestone : W01-358-7731

1/4NPTF centered air inlet, 3/8-16UNC blind nuts, 44.5mm screw center disrance

165mm Max. rubber bellow diameter, 50mm Min. height, 115 Max. height

1B7731B

Firestone : Bellow 131

1/4NPTF offset air inlet, 3/8-16UNC blind nuts, 44.5mm screw center disrance

165mm Max. rubber bellow diameter, 50mm Min. height, 115 Max. height

1B1209

Firestone : W01-M58-6165

Contitech : FS 120-9

Dunlop(FR) : 8’’x1 S08101
Bosch : 822419003
Festo : EB-215-80
Norgren : PM/31081(8x1)
Weforma : WBE 300-E1
Airtech : 140293
: 111003/1B-190FB
Megatech : 1S120-9 3/4 M8

G3/4 air inlet, M8 blind nuts, 70mm screw center disrance

215mm Max. rubber bellow diameter, 50mm Min. height, 115 Max. height

1B1209-1/4

Firestone : W01-M58-6166

Contitech : FS 120-9
Dunlop(FR) : 8’’x1 S08100
Bosch : 822419008
Weforma : WBE 300-E2

G1/4 air inlet, M8 blind nuts, 70mm screw center disrance

215mm Max. rubber bellow diameter, 50mm Min. height, 115 Max. height
