CONNECT Rock Ride DC 196781 Air Suspension Spring Bags Firrestone W21-760-6781 Replacement
CONNECT Rock Ride DC 196781 Firrestone W21-760-6781 Double Convoluted Air Suspension Spring Bags Replacement
Basic Information
Type: Air Suspension Spring
Fitment Type: Direct Replacement
Brand: Netural Or As Customer's Request
Upper Mount Type: Stud
Material: Rubber and steel
Manufacturer Warranty: 1 Year
Features: Sealed
Cross Reference
| Air suspension supplier/competitior | Firestone |
| Supplier/competitior number | W21-760-6781; W21 760 6781; W217606781; w21-760-6781; w21 760 6781; w217606781; |
| Air suspension supplier/competitior | Rock Ride |
| Supplier/competitior number | DC 196781; DC196781 |
Specifications and Detailed Technical Parameters
1. The top cover plate studs/ bolts: 2pcs× M10× 1.5
The screw center distance on top cover plate : 45mm
2. The bottom cover plate blind nuts: 1pc×M8x1.25, centered
3. Air inlet/air fittings/ air holes: 1/4NPTF
4. Natural Rubber bellow diameter:146mm
5. The max. rubber bellow diameter: 165mm
6. Design height: 153mm
7. Stroke: 78-190mm
8. Bumper block: Without
9. Top cover plate diameter: 111mm
10. Bottom cover plate diameter: 111mm
Other models we could offer
Reference
Rock Ride DC 196397
Rock Ride DC196397
Firestone W21-760-6397
Firestone W21 760 6397
Firestone W217606397
Firestone w21-760-6397
Firestone w21 760 6397
Firestone w217606397
Rock Ride DC 196401
Rock Ride DC196401
Firestone W21-760-6401
Firestone W21 760 6401
Firestone W217606401
Rock Ride DC 196902
Rock Ride DC196902
Firestone W01-358-6902
Firestone W01 358 6902
Firestone W013586902
Firestone WO1-358-6902
Firestone WO1 358 6902
Firestone WO13586902
Rock Ride DC 196910
Rock Ride DC196910
Firestone W01-358-6910
Firestone W01 358 6910
Firestone W013586910
Firestone WO1-358-6910
Firestone WO1 358 6910
Firestone WO13586910
Rock Ride DC 196905
Rock Ride DC196905
Firestone W01-358-6905
Firestone W01 358 6905
Firestone W013586905
Firestone WO1-358-6905
Firestone WO1 358 6905
Firestone WO13586905
Feature
Superior Fabric and rubber compound for durability and trouble-free
Reputation for Superior Performance
Reduce Driver Fatigue and Improve Concentration on the Road
Designed using the latest technological developments and improvements
The related picture of double convoluted air spring
