SP2B12R5 Phoenix Air Spring Cushion G1/4 Convoluted Rubber Bellows For Industrial Automation

This kind of air spring is produced by AIRSUSTECH, which is identified by the number 2B6910-G1/4 M10. We assure customers of its high quality and provide a one-year warranty. It is a cross to the Phoenix Air Spring double Convoluted brand SP 2 B 12 R.

The air spring is primarily made of rubber or synthetic rubber, which is chosen for its excellent elasticity and wear resistance. Adding fiber materials, such as glass fiber or carbon fiber, can enhance the structural strength and stability.

Valves and connections are necessary for air springs. They are typically made of metal or plastic, and their same job is to regulate the flow and pressure of gas inside the air spring. The type of gas filled in air springs is usually air, but it can also be nitrogen.

The pressure of the filling gas will decide the elasticity and load-bearing capacity of the air spring. With the proper combination of materials and the right pressure, the air spring will give excellent performance.

Features:

Firestone Cross Part Number: W01-M58-7894

Contitech Cross Part Number: FD 200-19 P04 1/4 M10

Goodyear Cross Part Number: 2B9-287

Phoenix Cross Part Number: SP 2B12R5

Phoenix Cross Part Number: S09208

Airkraft Cross Part Number: 113549

SAF Cross Part Number: 4.229.1004.00

PIRE-LLI Cross Part Number: T20

PIRE-LLI Cross Part Number: 86660

Taurus Cross Part Number: Kf216

Technical Parameters:

Data Measurement 1
Static Height (mm): 100
Pressure (bar): 1357
Force (kN): 2.27
Spring Rate (N/cm): 977
Natural Frequency (Hz): 3.28 Data Measurement 2
Static Height (mm): 100
Pressure (bar): 12
Force (kN): 17.3
Spring Rate (N/cm): 2296
Natural Frequency (Hz): 2.84 Data Measurement 3
Static Height (mm): 100
Pressure (bar): 3667
Force (kN): 2.75
Spring Rate (N/cm): 5026
Natural Frequency (Hz): 2.68

It is widely used in various drives and vibration isolation.
Air springs offer superior quality and performance using time-tested designs incorporating fabric-reinforced or natural rubber flexible member construction with corrosion protection and retainers.
As actuators, air springs can provide linear or angular motion.
Compared to air cylinders, these air springs have a good stroke-to-compression height ratio and can accept a variety of drive media such as air, water, nitrogen, or antifreeze.

Customization:

Packing and Shipping:

Phoenix Air Spring is well-packed with a cardboard box and a plastic bag to prevent any damage during shipping. The box contains a plastic air spring, a mounting kit, and installation instructions.

We use a trusted third-party shipping provider to ship Phoenix Air Spring. The orders are processed within 24 hours after receiving the payment. We ship to all countries around the world.

Once your order is shipped, you will receive a tracking number. You can use this tracking number to track your order.
