Natural Rubber Single Convoluted Air Spring W02-M58-3006 Firestone Sleeve Type Air Shock 1M1A-1
Product Description:
The Industrial Air Springs product is an excellent solution for industries that require air isolation, vibration reduction, and noise reduction. It is designed to provide a smooth and stable operation, even in the most demanding environments. This product is low maintenance, durable, and can withstand extreme temperatures, making it a long-lasting solution for any industrial application. Its air shock technology ensures that equipment and machinery are protected from external forces and reduces the impact of vibrations. With its high durability and low maintenance, this Industrial Air Springs product is a reliable and cost-effective solution for any industrial application.
Features:
- Product Name: Industrial Air Springs
- FIRESTONE Part NO.: W02-M58-3006
- MAX Load: 2.66 KN Force
- Cover Plate Material: Carbon Steel
- Pressure Range: 0.2-0.8 M PA
- MAX O.D. AT 4 BAR of Rubber Size: 86 Mm
- Keywords: Vibration Air Bags, Air Shock
Technical Parameters:
| Product Attribute | Value |
|---|---|
| Product Name | Air Vibration Bags, Industrial Air Spring, Pneumatic Bellows |
| Operating Temperature | -30°C to +70°C |
| MIN H. | 38 MM |
| MAX H. | 113 MM |
| Air Connections | 1/8 BSP AIR INLET |
| Rubber Type | Natural Rubber And Cord |
| MAX O.D. AT 4 BAR of Rubber Size | 86 Mm |
| Material | Rubber |
| MAX Load | 2.66 KN Force |
| MIN Load | 1.79 KN Force |
| FIRESTONE Part NO. | W02-358-3006 |
Applications:
- Heavy machinery
- Construction equipment
- Transportation vehicles
- Material handling equipment
These air springs are highly versatile and can be used in a variety of scenarios, including:
- Supporting heavy loads
- Reducing vibrations and shock
- Providing cushioning and suspension
- Compensating for height differences
Packing and Shipping:
Product Packaging for Industrial Air Springs:
- Each air spring is individually wrapped in plastic to protect it from damage during transportation.
- All air springs are then placed in a sturdy cardboard box with cushioning material to prevent any movement or damage.
- The box is sealed with strong tape to ensure the air springs remain secure.
Shipping Information:
- Shipping is available worldwide.
- The product will be shipped within 2-3 business days of placing the order.
- Shipping rates will depend on the destination and quantity of air springs ordered.
- Tracking information will be provided once the order has been shipped.
