Industrial Firestone Air Bags W01-358-7767 Steel Plate Double Convoluted Air Spring

Product Description:

Technical Parameters:

Here is the information about the product:

The product is made with 2-Ply Standard Cord

The end closure details have been provided:

• Bead ring type: 4
• Dim. C (Bolt Circle Diameter mm): 419
• # of Bolts (each ring): 24

Here are the specifications for the Airmount Isolator:

• Design Height (mm): 241
• Load (at Design Height) at: 3 Bar (kN): 34.9
• Load (at Design Height) at: 5 Bar (kN): 80.6
• Load (at Design Height) at: 7 Bar (kN): 84.5
• Natural Frequency (@5 Bar)(fn(Hz): 1.6
• % of Isolation at Forced Frequency 7 Hz: 93.9
• % of Isolation at Forced Frequency 13 Hz: 98.5
• % of Isolation at Forced Frequency 25 Hz: 99.6

The dimensions of the product are:

• Maximum Diameter @ 7 Bar (mm): 508
• Maximum Height (mm): 84
• Maximum Stroke (mm): 183
• Minimum Usable Height (mm): 267

Here is the force in kN for various strokes and pressures:

• Force in kN @ 5 Bar at Stroke of 25 mm: 86.3
• Force in kN @ 5 Bar at Stroke of 50% of Max Stroke: 75.1
• Force in kN @ 5 Bar at Stroke of Maximum Stroke: 52.1

The product's High Strength Style Number is 218.

Applications:

Airbag assist spring products have a variety of applications. This product can be used in a variety of commercial vehicles such as trucks, trailers and buses. This product can be used in vehicles that carry heavy loads to ensure a smooth ride and increase stability. It can also be used in vehicles that require height adjustment, such as motorhomes or RVs. Firestone airbags can also be used in the agricultural field and can be used to improve the suspension of tractors, harvesters and other agricultural machinery.

Airbags are widely used and can be used in a variety of scenarios. This product can be used off-road to ensure a smooth ride and increase stability. This product can also be used in emergency vehicles such as ambulances to ensure that patients ride safely and comfortably. It can also be used in military vehicles to ensure a smooth ride and increase stability. Airbags are also used in the automotive industry and are used in passenger cars to improve ride quality and increase stability.
