Contitech FS 200-10 Air Spring Suspension Single Convoluted Air Bags G1/4 Gas Hole
Contitech FS 200-10 Air Spring Suspension Single Convoluted Air Bags G1/4 Gas Hole
Product Description:
Expertly designed to provide superior performance and versatility for a wide range of applications. At the heart of its robust construction is a crimped assembly that ensures enhanced strength and durability. This is complemented by a convoluted bellow, meticulously crafted from Natural Rubber. This material is renowned for its exceptional dynamic capabilities and excellent universal properties, making our actuator not only powerful but also adaptable to a variety of operating conditions.
| Gas Hole | G 1/4 |
| Top Plate Hole/Stud Qty | 2×M10×1.5 |
| Bottom Plate Hole/Stud Qty | 2×M10×1.5 |
| Top Cover Plate Diameter | 160 mm |
| Bottom Cover Plate Diamtere | 160 mm |
| MAX. Diameter | 220 mm |
| Distance Gas Hole Between Nut | 44.5 mm |
| Distance Between Nuts | 89 mm |
| Natural Height | 110 mm |
Pneumatic application - static characteristic values:
| Pressure p [bar] | 3 | 4 | 5 | 6 | 7 | 8 | Vol. V [I] | |
| Height H [mm] | 120 | 5.36 | 7.24 | 9.18 | 11.2 | 13.2 | 15.3 | 3.1 |
| 110 | 6.09 | 8.21 | 10.4 | 12.6 | 14.8 | 17.2 | 2.9 | |
| 100 | 6.85 | 9.2 | 11.6 | 14 | 16.5 | 19 | 2.6 | |
| 90 | 7.37 | 9.88 | 12.4 | 15 | 17.7 | 20.3 | 2.4 | |
| 80 | 7.85 | 10.5 | 13.2 | 15.9 | 18.7 | 21.5 | 2.1 | |
| 70 | 8.36 | 11.2 | 13.9 | 16.8 | 19.7 | 22.6 | 1.8 | |
| 60 | 8.68 | 11.5 | 14.5 | 17.4 | 20.3 | 23.3 | 1.5 | |
Cross References:
Contitech: FS 200-10, FS 200 10, FS200-10, FS20010
Firestone: W01-M58-6374, W01 M58 6374, W01M586374, WO1-M58-6374, WO1 M58 6374, WO1M586374
Phoenix: SP 1B 12, SP1B 12, SP 1B12, SP1B12
Bosch: 822419004
Dunlop(FR): 9’’1/4x1 S09101
Festo: EB-250-85, EB 250 85, EB25085
Norgren: PM/31091(81/4x1)
Support and Services:
AIRSUSTECH Air Bags Product Technical Support:
- Provides additional support for your vehicle's suspension system
- Helps to reduce vehicle sagging, sway, and bottoming out
- Easy to install and inflate/deflate as needed
- Constructed with high-quality materials for durability and longevity
- Available in a variety of sizes to fit most vehicles
AIRSUSTECH Air Bags Product Services:
- Professional installation available through authorized dealers
- Warranty included with product purchase
- Online resources available for product information and troubleshooting
- Customer service available for any questions or concerns
The Real Pictures of 1B200-10 Air Springs
