Air Spring Suspension Replaces Firestone W01-358-7400 1/4 NPT Air Bags Assembly
Air Spring Suspension Replaces Firestone W01-358-7400 1/4 NPT Air Bags Assembly
Product Description
The actuator also features top and bottom plates that are crimped and coated with a zinc plating. This addition serves to provide excellent corrosion resistance, ensuring that the actuator maintains its high-quality performance over time. With its unique combination of power, adaptability, and durability, our Convolution Air Actuator stands as a dependable choice for any industrial requirement.
Product Information
| Cover Plate Top Cover Plate Diameter: 9.00 in. Screw Center Distance of Top Cover Plate: 6.20 in. Bottom Cover Plate Diameter: 9.00 in. Screw Center Distance of Bottom Cover Plate: 6.20 in |
| Nut/Blind Nut Top Cover Plate Screw(Nut) Tooth: 3/8-16 blind nuts Bottom Cover Plate Screw(Nut) Tooth: 3/8-16 blind nuts |
| Gas Hole/Air Inlet/Air Fitting Gas Hole: 1/4 NPT |
| Rubber Bellow Rubber Bellow Max Dia: 12.9 in. Minimum Height: 3.2 in. Maximum Height: 12 in. |
With The Same Firestone Style 22 Has Other Air Springs
- Blind nuts, 1/4 NPT, bumper
- Blind nuts, 1/4 NPT
- Blind nuts, 3/4 NPT
- Countersunk steel bead rings, 15/8 bolts, nuts, washers
- Rubber bellows only
Applications
The industrial air spring widely used in paper-making machinery, vehicle detection equipment, mechanical gripper, shaking table ect. to effectively improve the working efficiency, safety and service life of the equipment. In these fields, the products plays an important role of damping, lifting, supporting, and so on. It helps customers to save manufacturing costs and win more economic profits.
1. The products features low cost, wide use and easy operation.
2. It achieves long service life, and requires no maintenance and lubrication.
3. This product allows for flexible expansion and contraction, strong loading capacity, convenient design, and simple structure.
4. It comes with no friction and soft medium.
Product Core Competitiveness
1. Imported rubber
It is smelted with advanced sol technology, which improves the acid resistance, corrosion resistance and longer life of the product.
2. One-piece casting process
Adopt one-piece casting process, durable, strong air tightness, anti-leakage, high density of skin, anti-burst.
3. Ensure in-situ installation
The shape and size are the same as the original, directly replace the original air spring, no need to change, easy to install.
4. Using high-quality steel
Made of high-quality steel, anti-fracture, corrosion-resistant, long service life.
The Real Pictures
