350MM Diameter Double Convoluted Yokohama Air Spring S-300-2R for Punch Press
350MM Diameter Double Convoluted Yokohama Air Spring S-300-2R for Punch Press
Product Characteristics
① Design Height: 110 mm
② Max. Usable Height: 158 mm
③ Minimum Height: 53 mm
④ Full Stroke: 105 mm
⑤ Compression Max Outside Diameter: 360 mm
⑥ Maximum Internal Pressure: 0.88 MPa
⑦ Bellows Type: double convoluted
Product Technical Parameters
| Approximate value at standard height and internal pressure of 0.49 MPa | ||||
| Effective Area (cm2) | Volume (L) | Load (KN) | Dynamic Spring Constant (n/mm) | Natural Vibration Frequency (Hz) |
| 710 | 7.4 | 34.7 | 745 | 2.3 |
Same Outer Diameter 350MM Punch Air Springs We Have
| AIRSUSTECH NO. | Yokohama Reference No. | Hight H(mm) | The Largest Diameter When Compressed(mm) | ||
| Design High(mm) | Maximum High(mm) | Minimum Height(mm) | |||
| F-300-1 | S-300-1 | 72 | 117 | 40 | 400 |
| F-300-2 | S-300-2 | 98 | 158 | 53 | 360 |
| F-300-3 | S-300-3 | 152 | 242 | 82 | 360 |
AIRSUSTECH Cross YOKOHAMA Rubber Air Springs
| F-120-3 | S-120-3 | F-160-3 | S-160-3 |
| F-120-4 | S-120-4 | F-160-4 | S-160-4 |
| F-200-2 | S-200-2 | F-240-2 | S-240-2 |
| F-200-3 | S-200-3 | F-240-3 | S-240-3 |
| F-200-4 | S-200-4 | F-240-4 | S-240-4 |
| F-300-2 | S-300-2 | F-350-2 | S-350-2 |
| F-300-3 | S-300-3 | F-350-3 | S-350-3 |
| F-300-4 | S-300-4 | F-350-4 | S-350-4 |
| F-400-2 | S-400-2 | F-450-2 | S-450-2 |
| F-400-3 | S-400-3 | F-450-3 | S-450-3 |
| F-500-2 | S-500-2 | F-600-2 | S-600-2 |
| F-500-3 | S-500-3 | F-600-3 | S-600-3 |
| F-500-4 | S-500-4 | F-600-4 | S-600-4 |
| F-600-5 | S-600-5 |
FAQ
Q: What is the model number of the Punch Air Spring?
A: The model number of the Punch Air Spring is F-300-2.
Q: What are the packaging details for the F-300-2 Punch Air Spring?
A: The Punch Air Spring are packaged in strong carton boxes or as per the customers' requirements.
Q: How long does it take to get product after placing the order?
A: The delivery time of your ordered product varies as per what you've ordered and the shipping method that you've chosen. The estimated delivery time is mentioned during the checkout process, so be carefree while shopping.
The Picture of AIRSUSTECH F-300-2 Punch Rubber Air Spring
Technicians Measure the Dimensions of AIRSUSTECH Air Springs
Advanced Production Equipment
