22kW Smart Home and Commercial Wallbox EV Charger with RFID, WiFi and OCPP Support
Product Overview
The H Series 22kW Smart Wallbox EV Charger is designed to provide reliable and intelligent charging solutions for both residential and commercial environments. Featuring a compact modern design, advanced connectivity options, and dynamic load balancing technology, this AC EV charger delivers efficient and safe charging for various electric vehicles equipped with a Type 2 connector.
Supporting WiFi, Bluetooth, LAN, optional 4G communication, and OCPP protocol, the charger enables remote monitoring, charging management, and seamless integration with commercial charging platforms. Whether installed in private garages, apartment buildings, office parking lots, shopping centers, hotels, or public charging stations, the H Series Wallbox offers stable performance, flexible installation, and an enhanced user experience.
Product Features
- Up to 22kW AC charging power for faster and more efficient charging.
- Intelligent dynamic load management automatically adjusts charging power to optimize energy consumption and reduce electricity costs.
- Supports RFID authentication, SmartLife App, EV Wolfbox App, WiFi, Bluetooth, LAN, and optional 4G connectivity.
- Compatible with OCPP 1.6 JSON and optional OCPP 2.0.1, making it ideal for commercial charging network management.
- Equipped with a 4.3-inch LCD display and dynamic LED charging indicator for clear operating status.
- Built with multiple safety protections including Type B RCD, overload protection, leakage protection, and intelligent temperature control for reliable long-term operation.
- Durable PC enclosure with IP54/IP66 waterproof rating and IK10 impact resistance, suitable for indoor and outdoor installations.
Specificaiton
| Item | 22KW (Socket) | 22KW (Cable) | 7.4KW (Socket) | 7.4KW (Cable) |
|---|---|---|---|---|
| Dimensions (mm) | 530×350×250 | 530×350×250 | 530×350×250 | 530×350×250 |
| Weight | 4.6KG | 7.7KG | 4.2KG | 6.7KG |
| Operating Temperature | -30℃ ~ 55℃ | -30℃ ~ 55℃ | -30℃ ~ 55℃ | -30℃ ~ 55℃ |
| Storage Temperature | -40℃ ~ 85℃ | -40℃ ~ 85℃ | -40℃ ~ 85℃ | -40℃ ~ 85℃ |
| Material | PC | PC | PC | PC |
| Certifications | TUV-Mark / CE / UKCA / EN18031 | TUV-Mark / CE / UKCA / EN18031 | TUV-Mark / CE / UKCA / EN18031 | TUV-Mark / CE / UKCA / EN18031 |
| Charging Power | Up to 22KW | Up to 22KW | Up to 7.4KW | Up to 7.4KW |
| Charging Current | 6A / 8A / 16A / 24A / 32A | 6A / 8A / 16A / 24A / 32A | 6A / 8A / 16A / 24A / 32A | 6A / 8A / 16A / 24A / 32A |
| Voltage | AC 230V/400V 50HZ/60HZ | AC 230V/400V 50HZ/60HZ | AC 230V/400V 50HZ/60HZ | AC 230V/400V 50HZ/60HZ |
| Charging Socket | Type 2 | Type 2 | Type 2 | Type 2 |
| Charging Cable | Type 2 | Type 2 | Type 2 | Type 2 |
| Ammeter | MID/PTB | MID/PTB | MID/PTB | MID/PTB |
| Energy Metering | (±2%) accuracy on readings | (±2%) accuracy on readings | (±2%) accuracy on readings | (±2%) accuracy on readings |
| User App & Configuration | SmartLife / EV Wolfbox | SmartLife / EV Wolfbox | SmartLife / EV Wolfbox | SmartLife / EV Wolfbox |
| Charging Status | Dynamic LED Ring | Dynamic LED Ring | Dynamic LED Ring | Dynamic LED Ring |
| Display | 4.3" LCD | 4.3" LCD | 4.3" LCD | 4.3" LCD |
| Authentication | RFID | RFID | RFID | RFID |
| Network Connection | WiFi & Bluetooth, LAN & 4G (Commercial Optional) | WiFi & Bluetooth, LAN & 4G (Commercial Optional) | WiFi & Bluetooth, LAN & 4G (Commercial Optional) | WiFi & Bluetooth, LAN & 4G (Commercial Optional) |
| OCPP | OCPP 1.6 JSON / OCPP 2.0.1 (Commercial Optional) | OCPP 1.6 JSON / OCPP 2.0.1 (Commercial Optional) | OCPP 1.6 JSON / OCPP 2.0.1 (Commercial Optional) | OCPP 1.6 JSON / OCPP 2.0.1 (Commercial Optional) |
| RCD | Type B | Type B | Type B | Type B |
| Fire Classification | UL94-V0 | UL94-V0 | UL94-V0 | UL94-V0 |
| IP Rating | IP54 | IP66 | IP54 | IP66 |
| Impact Resistance | IK10 | IK10 | IK10 | IK10 |
| OPDDS Detection | Integrated in UK Mode | Integrated in UK Mode | Integrated in UK Mode | Integrated in UK Mode |
