LCD Lifepo4 15S2P Rechargeable Power Station 48v 200ah Solar Lithium Battery
Energy Storage System Lifepo4 Battery 48v 200ah Solar Battery Lithium Battery
|
Electrical Characteristics |
Model |
48V 200Ah (Customizable LCD) |
|
Energy |
9600Wh |
|
|
Internal Resistance |
≤100mΩ |
|
|
Cycle Life |
≥4000 cycles @1.0C 100%DOD |
|
|
Months Self Discharge |
<3% |
|
|
Standard Charge |
Charge Voltage |
53.2~54V |
|
Charge Mode |
0.2C to 54V, then 54V,charge current to 0.02C (CC/CV) |
|
|
Charger Current |
20A |
|
|
Max. Charge Current |
50A |
|
|
Charge Cut-off Voltage |
57.6±0.2V |
|
|
Standard Discharge |
Continuous Current |
20A |
|
Max continuous discharge current |
50A |
|
|
Discharge Cut-off Voltage |
37.5V |
|
|
Environmental |
Charge Temperature |
0 ℃ to 45 ℃ (32℉ to 113℉) @60±25% Relative Humidity |
|
Discharge Temperature |
-20 ℃ to 60 ℃ (-4℉ to 140℉) @60±25% Relative Humidity |
|
|
Storage Temperature |
0 ℃ to 40 ℃ (32℉ to 104℉) @60±25% Relative Humidity |
|
|
Mechanical |
Cell & Method |
3.2V50Ah 15S2P |
|
Shell material |
iron |
|
|
Dimensions |
442*450*250mm |
|
|
Weight (lbs./kg.) |
Approx: 73.5kg |
|
|
Gravimetric specific energy |
90.5WH/KG |
