Electrical Control C Frame Hydraulic Press 380V High Speed 16t - 630t
Price:
As discuss
MOQ:
One set
Delivery Time:
It depends on the actual situation
Brand:
Gracias
Product Description
C Frame Hydraulic Press
Feature:
- the use of advanced PLC hydraulic transmission technology, high science and technology, low failure rate, high degree of automation, high work efficiency.
- the main engine structure is compact, covers an area of small, easy to move and transport.
- high compactness of pressed products, not easy to break.
- the hydraulic pump station structure design is reasonable, highly centralized hydraulic control valve block and unique oil circuit design make the hydraulic system perfect, effectively achieve continuous normal production.
- program to achieve man-machine interaction, simple operation, convenient and fast.
- low rate, small calorific value, high working efficiency, power saving and durable.
Parameter:
| Model | Unit | 16T | 20T | 40T | 60T | 100T | 160T | 200T | 315T | 400T | 500T | 630T |
| Capacity | KN | 160 | 200 | 400 | 600 | 1000 | 1600 | 2000 | 3150 | 4000 | 5000 | 6300 |
| Pressure | Mpa | 20 | 18 | 22 | 25 | 26 | 25 | 25 | 25 | 26 | 28 | 28 |
| Travel | mm | 200 | 200 | 260 | 350 | 500 | 500 | 500 | 500 | 500 | 500 | 600 |
| Max Opening height | mm | 400 | 400 | 500 | 500 | 800 | 800 | 800 | 800 | 1200 | 1200 | 1200 |
| Throat depth | mm | 150 | 200 | 200 | 250 | 350 | 350 | 300 | 400 | 500 | 500 | 600 |
| Table Size | mm | 400*300 | 500*400 | 500*400 | 600*400 | 700*600 | 900*600 | 700*570 | 1250*800 | 1250*900 | 1500*900 | 1200*1200 |
| Table height | mm | 700 | 700 | 700 | 600 | 700 | 730 | 810 | 864 | 945 | 1000 | 1300 |
| Motor Power | Kw | 2.2 | 2.2 | 4 | 4 | 5.5 | 7.5 | 7.5 | 15 | 18.5 | 15*2 | 15*2 |
| Weight | Kg | 450 | 650 | 920 | 1400 | 2450 | 3700 | 4700 | 10500 | 15500 | 18500 | 25000 |
