50L Automatic Filling Packing Machine 20bph Bottle Screw Capping Machine
50L Automatic Filling Packing Machine 20bph Bottle Screw Capping Machine
Machine characteristics
① The whole machine is made of corrosion-resistant stainless steel, which is easy to clean and disinfect, and meets the national regulations and requirements on food machinery and hygiene.
② This machine adopts German brand infrared sensor, and its position control is accurate.
③ This machine adopts imported PLC and 7-inch touch screen man-machine interface, production parameterized control, simple operation.
④ Equipped with height and width adjustment handwheels, it is convenient to adjust the height and left and right width of the labeling head to adapt to different products.
⑤ Adopt imported high-precision servo motor to drive labeling, labeling is accurate and stable.
Capping machine
| Lid feeding form | Raise the belt style cover |
| Suitable specifications | According to the model provided by the customer |
| Capping form | Gripper cover to take the pneumatic screw cap(different specifications need to change the head and other accessories) |
| Speed | 20bottle/min |
| Total power | 500W |
| Air pressure | 0.6-0.8Mpa |
| Voltage | 220V Simplex |
4 Piston filling machine
| Filling heads | 4 heads |
| Filling capacity | 50-500ml |
| Filling form | Servo piston type |
| Speed | 25-30bottle/min(50-150ml) |
| Accuracy | +-1% |
| Air pressure | 0.6-0.8Mpa |
| Transport the motor | 370W Variable frequency speed control motor |
| Power | 2KW/380V 3 phase 5 line |
| Trough capacity | 50L |
| Protective device | Liquid storage tank will alarm if lack of liquid |
