32700 LiFePO4 Battery Cell 3.2V 6Ah | UN38.3 Certified, High Power
Lithium Iron Phosphate Cell 32700 3.2V 6000mah Lifepo4 Cylindrical Battery
| Item | Condition/ Note | Specification | Remarks | |
| 2.1 Nominal Capacity | 1C discharge capacity |
6.0 Ah |
||
| 2.2 AC Impedance | At AC 1000 Hz |
6.5 mΩ |
||
| 2.3 Nominal Voltage |
3.2 V |
|||
|
2.4 Cell Size |
Cell Diameter |
32.2±0.3 mm Max. 32.5 mm |
For details, please prefer to Figure 1. | |
| Cell Height |
70.5±0.3 mm Max. 70.8mm |
|||
| 2.5 Cell Weight | (Cell net weight) |
140± 5 g |
||
| 2.6 End-of-charge Voltage | CC Mode |
3.65 V |
||
| 2.7 End-of-charge Current | CV Mode |
0.3 A |
||
|
2.8 Charging Method |
Standard Charging |
1 C at CC/CV |
60 min |
|
| Max Continuous Charging |
6 C at CC/CV |
10 min |
||
| 2.9 End-of-discharge Voltage | CC Mode |
2.0 V |
||
| 2.10 Max continuous Discharging Current |
36 A |
|||
| 2.11 Max Pulse Discharging Current |
60 A |
3s |
||
| 2.12 Cycle Life |
1 C/ 100 % DOD |
≥2000 cycles |
||
|
2.13 Operating Temperature Range |
Charging Temperature |
0~60 °C |
||
| Discharging Temperature |
-20~ 60°C |
|||
| Storage Temperature | 1 year |
-20~ 45°C |
||
| 2.14 Appearance | Without break, scratch, distortion, contamination, leakage and so on | |||
Cell Diagram
Cell Picture:
Testing curves
What is an Lifepo4?
The LiFePO4 32700 Cell is a type of Lithium Iron Phosphate Cell that provides superior storage and delivery of power. It has a discharge cut-off voltage of 2.5V, an internal resistance of 6.5mΩ, a max discharge current of 30A continuously, an operating temperature between -20℃ and 60℃, and a max charge voltage of 3.65V. Thanks to its high energy density, the LiFePO4 32700 Cell is suitable for numerous high-demand applications such as electric vehicles, smart grid systems, and UPS systems. Its superior temperature characteristics, high safety, and low self-discharge rate make it a great choice for long-term storage and reliable power supply.
The LiFePO4 32700 Cell is designed for maximum performance, reliability, and efficiency. It is a lightweight and compact power source that provides high-performance power storage and delivery. Its superior performance characteristics make it a great choice for any application that requires reliable, long-term power storage and delivery. If you're looking for a reliable, powerful, and lightweight power source, then the LiFePO4 32700 Prismatic Cell is the perfect choice. With its superior temperature characteristics, high safety, and low self-discharge rate, it's the perfect choice for long-term storage and reliable power supply.
Why choose Benergy Lifepo4?
Design:
Safety is the most important for battery using.
Brand:
Quality:
* Professional Lithium Iron Phosphate Cell Maker since 2009 when Lifepo4 cell technology is still quite new.
Application:
Lifepo4 Cell 32700 can be widely use for solar system, Robot, AGV, electric vehicles, power tools, UPS and so on.
Certification:
FAQ:
- Q1: What is LiFePO4 32700 Cell?
- A1: LiFePO4 32700 Cell is a rechargeable lithium iron phosphate battery produced by Benergy, with model number BNG327006, manufactured in China.
- Q2: What is the voltage of Benergy BNG327006?
- A2: Benergy BNG327006 has a nominal voltage of 3.2V.
- Q3: What is the capacity of Benergy BNG327006?
- A3: Benergy BNG327006P has a nominal capacity of 6Ah.
- Q4: What are the size and weight of Benergy BNG327006?
- A4: Benergy BNG327006 has a size of 330mm*170mm*170mm and a weight of 9.6kg.
- Q5: Does Benergy BNG327006 include a protection circuit module?
- A5: Yes, Benergy BNG327006 includes a protection circuit module.
