High Speed Pharmaceutical Packaging Machines , Capsule Blister Machine CE Standard
DPP-140H Automatic High Speed Blister Packing Machine CE Standard
Simple Introduction:
The machine is new product which is improved based on customer’s requirements. It’s suitable for packaging of all kinds of liquid and solid in large & medium pharmaceutical factory, health medicine factory, hospital preparation lab, food industry, electronic industry, hardware industry, etc. It can protect the material from steam or dust, improve product packing degree, and increase the additional value. The machine is used to produce large quality and single product.
Feature:
Speed is shifted by step-less transducer. Adopt the interface of human-machine and PLC programmable controller, it can synchronize accurately.
Adopt the equipment of trace pressing, batch number printing and scarp-collecting.
Stepping motor drives and tow materials.
The heating moulds will automatically separate when the machine stops, which contributes to protect the material between them and extend the machine’s life.
Technical parameters:
| Model | DPP-140H |
| Blanking frequency(cutting) | 5-50 |
| Sheet's quantity of one blanking (sheets) | 1-4(depends to your blister size) |
| Wrapper Specification(PVC) |
Width:10-150mm |
|
Wrapper Specification(PTP Alu Foil) |
Width:10-150mm |
|
Power supply (KW) |
220V AC, 30 Hz, Three Phase (Depend on your requirement.) |
|
Capacity of air compressor(m3/min) |
≥0.36 |
|
Weight |
950Kg |
