Customized LiFePO4 60V 72V Lithium Ion Motorcycle Battery For EV Cars

Price Negotiable

Price: negotiable

MOQ: 10PCS/ORDER

Delivery Time: 3-5days

Brand: Purple Horn

Product Description

Customized LiFePO4 48V 60V 72V Electric Vehicle Battery Lithium Ion Pack for EV Cars/Storage System

Product Introduction

Every Lithium Battery we offer is built with a Fail Safe Built in Battery Protection System (BMS).

LiFePO4 battery 72V 48V 60V 100Ah , created by the use of Iron (Fe) as a cathode material. LiFePO4 cells have a higher discharge current, do not explode under extreme conditions and weigh less.

Product Details

Item		48V50Ah	48V100Ah	60V40Ah	60V100Ah	72V30Ah	72V100Ah
Dimension (including terminals)		350x305x220mm	560x520x270mm	400x180x290mm	560x340x280mm	480x180x290mm	560x330x330mm
Weight		Appx. 25Kg	Appx. 66.5Kg	Appx. 27Kg	Appx.70Kg	Appx. 24Kg	Appx.76Kg
Min. capacity		50Ah (0.2C)@25℃	100Ah (0.2C)@25℃	40Ah (0.2C)@25℃	100Ah (0.2C)@25℃	30Ah (0.2C)@25℃	100Ah (0.2C)@25℃
Terminal		Customizable	Customizable	Customizable	Customizable	Customizable	Customizable
Voltage	Max.	58.4 V	56 V	73 V	73 V	87.6 V	87.6 V
	Nominal	51.2 V	51.2 V	64 V	64 V	76.8 V	76.8 V
	Min.	40 V	40 V	50 V	50 V	60 V	60 V
Max. Continuous Discharging Current		≤50A	≤150A	≤40A	≤50A	≤30A	≤100A
Communication		CAN
Temp. Condition		Operation (Charge): 0 ~ 45℃
		Operation (Discharge) : -20 ~ 60℃
		Storage : -20 ~ 60℃
Self-Discharge Rate		100% SOC, 25℃, 1month: ≤3%
Cycle Life		0.2C, 100% DOD 25℃: 3,000 cycles
Abuse test		Overcharge, Over-discharge, Short, Heat,Nail, Crush GB/T 31485-2015
