CW PW Purple Horn Laser Welding Machine For Industry Stainless Steel
Product Description
Machine Features for handheld laser welding machine
2. No welding scars, smooth and beautiful
3. Welding welding is very firm
4. The welding head can be replaced to meet various welding needs
5. No technical requirements, anyone can weld perfectly
6. Almost no consumables, no grinding is required in processing process, material cost is low
7. The welding speed is fast, 1 worker can be used as 5 workers, labor cost is low
8. No dust and gas pollution, very environmentally friendly
| Model | ML-500w |
| Average laser power | 500w |
| Max laser power | 3000w |
| Max energy of single pulse | 75J |
| Laser wavelength | 1064nm |
| Laser weld depth | ≤ 2mm |
| Pulse width | 0.3-20ms |
| Laser welding frequency | 0.5 -100HZ |
| Spot size range | 0.2-2mm |
| Welding wire | 0.1-0.4mm |
| Power Supply | 380VAC ± 10% / 50-60HZ |
| Power Consumption | 2KW |
| Water pressure protection | 0.025MPa |
| Cooling water temperature | 35 degrees |
| Temperature protection | 45 degrees |
| Cooling water flow | 10L/min |
| Dimensional | 1100mm x 900mm x 1200mm |
| Weight | 320kg |
| Cooling Way | Water cooling |
| Laser Type | Pulse |
Gun Features for handheld laser welding machine
3) Adopt touch screen design, easy and quick to click and set, with real-time fault reading, feedback and alarm functions.
4) There is a process parameter library, which can realize the rapid storage and recall of cleaning process parameters.
Remote controller at the welder side for multi-parameters adjustment. Save time and effort, easy to operate.
Applications
Aviation Parts Domestic Appliance
Elevator Manufacturing Auto Parts
