120KN Biaxial Fiberglass Geogrid Material For Preventing Construction Road Cracks
120KN Biaxial Fiberglass Geogrid Material For Preventing Construction Road Cracks
Quick Detail:
material: glass fiber
function: reinforce, strengthen road, prevent road cracks
advantage: high temperature resistance, anti-aging, corrosion resistance, low cold resistance,
Product Description:
Glass fiber geogrid is a kind of excellent geotechnical material used for pavement reinforcement, old road reinforcement, subgrade reinforcement and soft soil foundation.It has become an irreplaceable material in the treatment of reflective cracks on asphalt pavement.The product is a semi-steel product made of high-strength alkali free glass fiber by international advanced light knitting process and surface coating.
It has high tensile strength and low elongation on both sides of the warp and weft, and has excellent properties such as high temperature resistance, low cold resistance, anti-aging and corrosion resistance.It is widely used in the reinforcement of asphalt pavement, cement pavement and subgrade, railway subgrade, dam slope protection, airport runway, sand control and other projects. It uses glass fiber non alkali and non twist roving as the main raw material and adopts certain weaving process to make the mesh mechanism material, which can protect the glass fiber and improve the overall performance.
Technical Parameter:
| features specs | GSB-30-30 | GSB-40-40 | GSB-50-50 | GSB-80-80 | GSB-100-100 | GSB-125-125 | GSB-150-150 | ||
| Grid Mesh Size | 12.7*12.7-25.4*25.4 | ||||||||
| Tensile Strength (≧ KN/m) | Vertical | 30 | 40 | 50 | 80 | 100 | 125 | 150 | |
| Horizontal | 30 | 40 | 50 | 80 | 100 | 125 | 150 | ||
| Elongation (%) | ≦4 | ≦4 | ≦4 | ≦4 | ≦4 | ≦4 | ≦4 | ||
| Temperature Resistance ℃ | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 | -100~280 | ||
Application:
- The old asphalt concrete pavement, reinforced to enhance the asphalt surface layer to prevent pavement collapse
-
Reconstruction of cement concrete pavement into composite pavement
-
Restrain reflection cracks caused by plate contraction
-
Road renovation project
-
Prevention and treatment of cracks caused by new and old joint and uneven settlement
-
The reinforcement treatment of soft soil foundation is conducive to the consolidation of soft soil, effectively restrain the settlement, uniform stress distribution and enhance the overall strength of subgrade
-
The shrinkage cracks are produced in the semi-rigid base of the new road, and the reinforcement is used to prevent the pavement cracks caused by the reflection of the foundation cracks
Advantage:
1) Maintenance and reinforcement of old asphalt road.
2) Rebuild old cement concrete road into composite road, restrain reflection crack caused by different block contraction.
3) It has widely applied in road renovation and expansion project, prevents cracks along the joint position caused by uneven sedimentation.
4) It is used for soft sub grade reinforcement. The geogrid will help the water infiltration and soil concretion, restrain subsidence effectively, and decentralize stress evenly, enhance overall strength of the roadbed.
Package:
Rolling with pipe in core, double layer woven bags with strengthened belt for unloading convenience and protecting.
Delivery:
It can be shipped in 7 days. Product will be loaded carefully to make sure it can be well received. 20GP Container can load around 19 tons, 40HQ 25 tons.
Factory Show:
Supply Ability:
25 tons per day
