Black Textured Perforated HDPE Geocell For Soil Reinforcement
Black Textured Perforated HDPE Geocell For Soil Reinforcement Stablization In Road Construction
Quick Detail:
material: PP, PET, High-density polyethylene (HDPE)
height: 50mm
function: reinforce, stablize, protection
application: road basement, highway, earthwork
Product Description:
FUYUN geocell is well known that an ideal soil material for use in civil engineering applications is one that compacts well and drains water freely. The problem is that the better draining soils are difficult to confine in place. Our Geo cellular confinement system provides a solution. It is being widely used in construction, such as highway, railway, bridge, dyke, etc.
It is manufactured from Virgin, high-density polyethylene. Standard panles contain 58 strips of HDPE ultrasonically welded at different distances depending upon the chosen product configuration wide. Each strip is between 3 to 8 inches (75 to 200mm), depending upon the cell depth, and 142 inches (3.6m) in length. Cells walls are textured and if perforations are required, between 9.5% and 14% of the cell wall is removed.
Technical Parameters:
| item | GS-50-400 | GS-75-400 | GS-100-400 | GS-150-400 | GS-200-400 |
| height(mm) | 50 | 75 | 100 | 150 | 200 |
| thickness of the sheet (mm) | ≧1.1 | ≧1.1 | ≧1.1 | ≧1.1 | ≧1.1 |
| weld distance (mm) | 330≦A<1000 | 330≦A<1000 | 330≦A<1000 | 330≦A<1000 | 330≦A<1000 |
| tensile strength of weld points (N/cm) | ≧100 | ≧100 | ≧100 | ≧100 | ≧100 |
| tensile strength of connection of cells (N/cm) | ≧120 | ≧120 | ≧120 | ≧120 | ≧120 |
| tensile strength at yield of each sheet(N/cm) | ≧20 | ≧20 | ≧20 | ≧20 | ≧20 |
Application:
1. stablize road and railway roadbeds.
2. withstand the load of gravity for the embankment and shallow water channel
3. prevent landslides and load gravity as hybrid retaining wall
4. When encountering soft foundation, the use of geocells can greatly reduce the construction labor intensity, reduce the thickness of the roadbed, and the construction speed is fast and the performance is good, which greatly reduces the construction cost
Advantage:
- Being flexible, transport can be folded, construction can be stretched into a network, filled with soil, gravel, concrete and other loose materials, constitute a strong lateral limit and stiffness of the structure.
- Flexible, small transport volume; The connection is convenient and the construction speed is fast.
- Light material, wearing resistance, chemical stability, light and oxygen resistance, aging, acid and alkali resistance, suitable for different soil and desert and other soil conditions.
- Higher lateral restrictions and anti-slip, anti-deformation, effectively enhance the bearing capacity of the roadbed and dispersed load.
- Different engineering needs can be met by changing the height and welding distance of geotechnical chamber.
Package:
the geocell is packed by strips on the wood pallet. it can also be packed by customer's special requirement. we gurantee the product good when customer receive it.
Delivery:
all products are delivered in time according to customer's requirement. we cooperate with international famous logistic company and shipping company to gurantee the safety of product and fast delivery.
