A3003 Aluminum Honeycomb Core Building Material Sandwich Panel For Mall Project
3003 Aluminium Building Material Sandwich Panel Aluminum Honeycomb Core for Mall Project
3000 Series commercial grade aluminum honeycomb is made from 3000 Series aluminum alloy foil.It is a lightweight core material offering excellent strength and good corrosion resistance for industrial applications at low cost.
* Regular Sizes and Max. Expaned Sizes of Aluminum Honeycomb Core
| Node | a=4 | a=5 | a=6 | a=7.5 | a=10 | a=12 | a=15 | a=20 |
| Cell Size (inch) | 1/4 | 1/3 | 3/8 | 1/2 | 3/4 | 4/5 | 1 | 1 |
| Max Sizes
(Length * Width) (mm)
|
1800*3100 | 1800*4000 | 1800*4600 | 1800*6000 | 1800*7500 | 1800*9000 | 1800*12000 | 1800*15000 |
| Model of Aluminum Foil Thickness (mm) | 0.04, 0.06 | 0.04, 0.06 | 0.04, 0.06 | 0.04 - 0.06 | 0.04 - 0.06 | 0.04 - 0.06 | 0.04 - 0.06 | 0.04 - 0.06 |
| Features: | • High thermal conductivity • Flame resistant • Good moisture and corrosion resistance • Fungi resistant • Low weight/High Strength |
Supplied form:
Expanded or unexpanded.
Full blocks or cut slices.
Perforated or un perforated.
Corrosion treated or untreated.
Our aluminum honeycomb is adhesive-bonded of the aluminum foil, which produces one of the highest strength and the highest
surface-to –volume ratio of any structural material. Our aluminum honeycomb is made from 3003H18 and 5052H18 aluminum alloy foil.
|
Product Name
|
aluminum honeycomb core
|
|
Material type
|
A3003H18 / 5052H18
|
|
Cell side length (mm)
|
5, 0.6, 0.7, 0.8, 0.9, 1.0, 1.5, 1.83, 2, 2.5, 3, 4, 5, 6, 7.5, 10, 12, 15 mm
|
|
Foil thickness
|
0.025-0.08 mm, 0.1mm
|
|
Height/Sheet Thickness
|
1.5mm to 500mm
|
|
Max Sheet Sizes
|
1700mm (L) x 8000mm (W)
|
|
Standard
|
CN, BS, ASTM
|
|
Capacity
|
50K m2/month
|
Applications:
Aluminum Honeycomb Core is widely used in electronic and industrial field which is including as below.
- Architectural Building Cladding and decoration
- Architectural Rainscreen Facades
- Lightweight interior architectural panels
- Tables and furnitures.
- Aerospace, Marine & Transport Flooring, Walls & Partitions
- Silk Screen Printing Tables
- CNC Vacuum Bases
- Lightweight Floors, Walls, Ceilings, etc
- Special Purpose Panel Design
Why choose WDF?
1:We produce honeycomb panel with more than 10 years experience.
We have professional team to offer clients total solution from design to finish, provide customer individual care.
2.Overall control over the whole production process from aluminum coils to finished panels.
We have production base of aluminum coils, honeycomb cores, aluminum sheet and composite panels.
3.Our team is dynamic, young, motivated, customer-oriented and diverse and you can reach us at 24/7.
4.Our products are tested , so you can rest assured that our quality is guaranteed.
