USLKG-50 UK Series DIN Rail Screw Clamp Grounding Terminal Blocks Replace Phoenix
Height mm | 62/69.5/67 |
Depth/Width/Plate depth mm | 15.2/50/- |
Current/Cross-section A/mm² | 150/50.0 |
Technical date IEC 60947-7-1
Rated date | IEC | UL | CSA | EN50019 |
Rated voltage | 1000 | 1000 | 600 | 750 |
Rated current | 150 | 150 | 112 | 145 |
Rated cross-section | 35.0 | AWG18-1 | AWG18-2 | 35 |
Rated impulse withstand/Pollution severity | 8KV/3 | |||
UL 94 flammability rating of insulation material | V-0 or V-2 | |||
Insulating material/Approval | PA66 | |||
(H05V/H07V) Lead Rated Cross-section
Solid/Flexible mm² | 2.5-50.0/2.5-35.0 |
Flexible with ferrule mm² | 2.5-35.0/2.5-35.0 |
Stripping length mm/in | 16 |
Screw-thread/Tightening torque Nm | M6/3.0-3.5 |
Order info
Color | Order No. | Pack.-unit pcs |
Green-yellow | 335904 | 50 |
