NMM-90L Turbine Type Wet Bead Milling High Wearing Resistant
High effective Turbine Type Horizontal Bead Mill Nano Grinding Mill
Product Description
Boyee offers you
1. Expert advice
2. A vast body of experenice and technical expertise ,particularly in mixing ,pre-dispersing ,wet grinding and de-aeration for a wide range of applications in many different industries
3. Utilization of the best commercially-available technology for the entire-process
4. A laboratory to assess the designed solution prior to implementation and to provide an appropriate performance guarantee
5. Entire production plants-we're with you form conception to completion and production.
Product Advantages
- Ultrafine grinding and dispersing technology, applicable for materials with different viscosities
- Ceramic (zirconia/ carborundum) grinding chamber to avoid pollution and improve purity of the material
- Mechanical seal with special design to facilitate stable operation
- Patented centrifugal discharge solution of Boyee which solves the blockage problem
- Better evenness for grinding with narrower peak of the distribution curve
- Independent electric box, optimized process control system and intellectual technology to help monitor the operation data
- Unique design for profile with reasonable structure and small space occupancy
- Equipment remain stale and quiet with little noise while running
- Ultrafine grinding media (as fine as 0.05mm) can be utilized without leakage or damage to the surface properties of the material
Operational safty
For increased operationaly safety,The mechanical seal fluid is monitored continously.These data can be documented and used for predictive maintenance to ensure high availability of the machine
Other Series
| Grinding Chamber |
Designed Volume: 90L Effective Volume: 98L |
| Inner Chamber material:Silicon Carbide | |
| Outer Materia: SS304 | |
| Grinding Ceramic and rotor material:Zirconia | |
| Cooling Mode: Cooling water passing through gridning chamber | |
| Mechanical Sealing |
Self-developed double acting mechanical seal. Sealing Support : SS304 |
| Dispersion & Grinding structure | Ceramic turbine grinding rotors |
| Dispersing linear speed | 10-15m/sec |
| Separating mode | static screen separation |
| Grinding Media |
95% zirconia beads Zirconia beads spec : Dia 0.3 mm- Dia 1.0mm Filling quantity recommended:70% ᷉ 80% |
| Power | 380V/50Hz |
| Dimension | 3290(L)x 1478(W)x 1950(H)mm |
| weight |
3050Kg
|
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
| Packaging | |
| Size | 1100*550*1650 |
| Weight | 80kg |
| Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
Best quality
Long-term experience, continual development work, daily contact with our customers and developments with more than 30 patents ensure the technical competence and the quality awareness of the business unit.
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for charge &you should pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
