Medium Voltage SWA Armored Cable YJV32 Underground Armoured Cable
Medium Voltage Copper Core SWA Armored Power Cable Underground Armoured Cable
Application:
Medium voltage cables are designed to distribute power with a rated voltage from 1.8/3KV to 26/35KV and a frequency of 50Hz.
It is mainly for installation in power supply stations, indoor and outdoors, underground for industries, distribution boards and power station etc
Characteristics:
Rated voltage:6-35 KV
Allowable long-term working temperature of cable conductor: 90℃
Allowable temperature of cable conductor during short circuit (long duration no more than 5s): 250℃
Ambient temperature during cable laying: not less than 0℃.
The bending diameter of a multi-core cable is not less than 15 times the outer diameter of the cable,
and the bending diameter of a single-core cable is not less than 20 times of the outer diameter of the cable.
National Standard: IEC 60502
| Product name | Medium Voltage Cables |
| Certifications | CE/CCC/ISO |
| Standard | IEC60502 |
| Rated Voltage | 6-35 KV |
| Conductor material | Copper/Aluminum |
| Insulation Material | XLPE |
| Armoured Material | None/Steel Tape/Steel wire |
| Jacket Material | PVC |
| Number of cores | 1 or 3 |
| Section area | 25 35 50 70 95 120 150 185 240 300 400 500 sqmm |
| Model | Name | Remark |
| N2XY, NA2XY | Copper core (aluminum core) XLPE insulated and PVC sheathed power cable | Laying indoors, tunnels and pipelines |
| N2XBY, NA2XBY | Copper core (aluminum core) XLPE insulated PVC sheathed steel tape armored power cable | |
| N2XRY, NA2XRY | Copper core (aluminum core) XLPE insulated PVC sheathed steel wire armored power cable |
Medium Voltage Cables
