High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter

Name: High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter
Brand: Anhui Wenyao Intelligent Photoelectronic Technology Co., Ltd

Price Negotiable

Price: 15000$-16000$

MOQ: 1

Delivery Time: 15 DAYS

Brand: WENYAO

Product Description

High Intelligent Ccd Full Color Sorter For Grains And Beans Cardamom Color Sorter

Product Description:

Multifunction Color Sorter Machine for Walnuts, Almond, Pistachio Separation

*Nuts Defects Sorting through High Resolution 4096 Pixel CCD Camera,High Reliability And Long Life LED Light Source;

*Efficient And Stable Software System, Intelligent Algorism, User Friendly Interface;

*Better Sorting Accuracy, Lower Carryover, And Bigger Production Capacity;

*SOC Platform To Realize Stable, Reliable, Ultra-Fast Mass Data Processing;

*Nuts Colour Sorting With Expert Sorting Solution Realizes One Key Debugging

Primary Working Principles of a Color Sorter Machine

So, what’s the primary working principle of a color sorting machine? Let’s break it down:

First, the CCD color sorter determines the light transmittance and color depth of the material in its feeding hopper by:

Taking high-definition pictures
Comparing the amplitude of the light source changes
Ejecting material that has an amplitude that exceeds the predetermined value

Now, consider the second working principle: when the mechanical separations begin, the materials must be distributed evenly into each channel. Then, the CCD camera in the sorting cabinet will detect the steadily flowing product. Upon identifying unqualified materials, the main control machine activates the spray valve, and the rejected product accelerates into the defective hopper.

Color sorters are integral to many businesses, particularly in the agricultural and food processing industry. For example, a color sorter can display seed images and swiftly sort through grains and harvested products with rapid efficiency, including:

Corn
Beans
Nuts
Fruits
Seeds
Peanuts
Plastic
Salt
Wheat
Tea
Dehydrated vegetables
Spices
Snacks
Oats
Coffee beans

Technical Parameters:

MODEL	WYCS4-256
Chutes(channels)	4(256)
Sorting accuracy(%)	≥99.9
Carryover rate (bad:good)	≥30:1
Output(T/h)	≥2
Voltage	180-240V/50Hz
Power supply(kw)	2.3
Work Air Pressure(Mpa)	0.2-0.3
Air consumption(L/min)	1000-2400
Air supply(Mpa)	0.6--0.8
Dimension(LWH) mm	185415601840
Weight(kgs)	750
Package	Plywood case
Package Size mm	216016802060

INTELLIGENT OPERATION SYSTEM

Overall Large Screen HD Operation control panel, 1080P Super high resolution,system more stable, more friendly Human-Machine-Interface panel, which gives high sensitivity instant fast repones in the industrial environment.

NEWLY SPECIAL SUPER WIDTH CHUTE DESIGN

Special technology chutes, applicable for universal materials,make the transfer more steady, more capacity.

MECHNICAL RECONSTRUCTION

Reconstrution of the mechnical frame, the main part with special material,balancing whole frame bearing, ensure the machine integrity. Working with the updated mechanism, it strength the base of the ultra-sorting.

SELF-DEVELOPED SPRAY VALVE

Self-developed spray valve, Self-developed high-performance spray valve, super high rapid response to the Algorithm results. It can continuously working 12billion+ times, extremely long life, with low air consumption,master the core technology.

ILLIMITABLE SORTING POSSIBILITIES, START BY “ONE BUTTON” PRESSURING

Hundred of sorting profiles can be saved in machine machine, for the variety products for sorting, subdivide the quality of agric and sideline products illimitable sorting possibilities,“one button”start, “one button”profiles exchange.

SHADOWLESS COLD LIGHT SOURCE,AUTOMATICA ADJUSTABLE

Extremely long life, low energy consumption intellligent shadowless cold light source, orthogonal spectrum technology, make the image more visiable, more accuracy detection; the output luminance of light source are automatically adjustable, it make the lights more stable with high quality. It is fully appliable for the camera to see and detect.

Why Choose Wenyao Color Sorter?

1. Over 17 years experience which focus on sorter machine. One of the most advanced manufacturer in Hefei, Anhui.

2. After-Sales service guarantee: We have a professional after sales service team, one-to-one customer service to help customers install and debug.

3. We have service station over Southeast Asia, cooperate reseller in more than 100 countries.

4. Quality assurance of raw materials: the raw material we purchase are certified qualified products.

5. Quality process assurance: We have been authorized by CE & ISO quality management system, each process of production are under strictly standard.

6. System test: Our technical engineers check the product performance, even every part is subjected to rigorous aging test to ensure that the factory products would being in full compliance with customer requirements.

7. Shipping guarantee: We have professional packaging operation team, independent export qualification to ensure product safety and stability to reach customers in hands.

Support and Services:

Our Grain Color Sorter product comes with comprehensive technical support and services to ensure smooth operation and maximum performance. Our team of experienced technicians and engineers are available to provide remote and onsite support, as well as training and consultation to help customers optimize their sorting process.

Our technical support services include troubleshooting and diagnosis of any technical issues, as well as recommendations for repair and replacement of parts. We also offer regular maintenance and calibration services to ensure that the machine continues to operate at peak efficiency.

In addition to technical support, we also offer customization services to meet unique sorting needs of our customers. This includes developing custom software and hardware modifications to enhance sorting accuracy and speed.

Our commitment to customer satisfaction means that we are always available to answer any questions or concerns related to our product. We strive to provide the highest level of support and service to help our customers achieve their sorting goals.
