Wenyao Colorful Plastic Sorting Machine Transparent Plastic Color Sorter Separator With Good Service Price

WENYAO Color Sorter Working Principle :

Color sorting machine is an equipment that automatically sorts out different color particles in granular materials by photoelectric technology according to the difference of material color.The selected material enters the machine from the hopper at the top, passes through the vibration of the vibrator device, slides down the channel, accelerates its descent into the observation area of the sorting room, and passes between the sensor and the background plate. Under the action of the light source, according to the intensity and color change of the light, the system generates output signals to drive the solenoid valve to blow out the different color particles into the waste material cavity of the receiving hopper, and the good selected material continue to fall into the finished product cavity of the receiving hopper, so as to achieve the purpose of selection.
Significance of color sorting machine:Compared with manual selection, labor-saving, time-saving, high efficiency, low processing cost.Improve the quality and economic and social benefits of selected products.

Technical Parameters:

Features:

1. High frequency solenoid valve
Special color sorting, high frequency, low power consumption,high sorting accuracy.Independently developed intelligent magnetic control high frequency solenoid valve for color sorter.Immediately response speed for valves opening insure sorting accuracy; quickly response speed for valves closing reduces the carry out ratio.Flexible contact og the valve plate makes service life of the valves extend to 60~100million times,10~30billion time more compared with other competitors.

2. ShadowlessLED lights can precisely focus the ray on the inspection line. The LED white light can identify any light color differences.

3. Nikon 5400px full color high resolution cameras, even it can recognize the smallest defects.

4. Automatic cleaning system with customized time, duration and delay to keep the machine working without time waste.

5. Humanized operation system is easy to operate. One-key intelligent automatic identify and adjust, meet the requirements of different batches and different impurity rate of the raw material.

FAQ:

How to get the correct size and price for Wenyao color sorting machine?
Please contact us according to the following questions if you need color sorter prices:
Step 1.What kinds of the material are you planning to sort processing?
Food materials:
Such as: Rice, Wheat, Corn, Soybean, Peanut, Sunflower seeds, Waltnut, Almond, Quinoa, Salt, Medlar, Pistachio, Kidney bean, Chili, Red bean, others.
Plastic materials:
Such as: Waste Plastics, Plastic pellet, Plastic pieces, Plastic granule, Plastic bottle cap flake, PET bottle scrap, ABS plastic flake, PP plastic scrap, Recycled plastic, others.
Mineral materials:
Such as: Quartz stone, Quartz sand, Potassium feldspar, Barite, Calcite, Limestone, Pearl, Marble and others.

Step 2.How much capacity(output) to sort processing for the raw materials per hour?
Such as: 200KGS, 500KGS, 1000KGS, 2000KGS and son on.
Step 3.In order to know the impurity rate of the raw materials that are needed to be sorted, please send us 3 pictures as following:
1. Raw material picture
2. Accepted material picture
3. Rejected material picture

Our service:

Before Sale:We will provide detailed solutions for your special requirement and help you know more about our color sorter.

After Sale :

1.We provide customer with one year free repair and maintenance for complete machine.
2.We also provide lifetime professional training and technical guidance service.

Sorting effects of plastic:

Other Application Fields:

Custom's site:
