High Precision 10 Chutes 4.5-16 T/h PE PVC PP HDPE PET Plastic Flakes Color Sorter Machine
High Precision 10 Chutes 4.5-16 T/h PE PVC PP HDPE PET Plastic Flakes Color Sorter Machine
WENYAO Plastic Color Sorter Machine Working Flow:
High Precision 10 Chutes 4.5-16 T/h PE PVC PP HDPE PET Plastic Flakes Color Sorter Machine
Technical Parameters:
High Precision 10 Chutes 4.5-16 T/h PE PVC PP HDPE PET Plastic Flakes Color Sorter Machine
Technic Parameter
| Model | WYCS6-384 | WYCS7-448 | WYCS8-512 | WYCS10-640 |
| Chute/Channel | 6/384 | 7/448 | 8/512 | 10/640 |
| Throughput(t/h) | 2.5-8 Ton /H | 3-10 Ton /H | 3.5-12 Ton /H | 4.5-16 Ton /H |
| Sorting Aaccuracy | ≥99.99% | ≥99.99% | ≥99.99% | ≥99.99% |
| Power | 3.1kw | 3.9kw | 5kw | 6.5kw |
| Power Voltage | 180-240V/50Hz | 180-240V/50Hz | 180-240V/50Hz | 180-240V/50Hz |
| Air Source Pressure | 0.6-0.8Mpa | 0.6-0.8Mpa | 0.6-0.8Mpa | 0.6-0.8Mpa |
| Air Consumption | <0.6M3/Min | <0.6M3/Min | <0.6M3/Min | <0.6M3/Min |
| Weight | 110kg | 1350kg | 150kg | 180kg |
| Diamension(L*W*H) | 2595*1540*1852mm | 2905*1540*1852mm | 3025*1540*1852mm | 3750*1540*1852mm |
High Precision 10 Chutes 4.5-16 T/h PE PVC PP HDPE PET Plastic Flakes Color Sorter Machine
Features:
CCD Camera
Japanese TOSHIBA 5340 line
ar CCD, core guarantee of high precision and quick sorting , the smallest to 0.04mm could be locked.
LED system
World leading stable long lifetime LED light, customized LED solution accepted according to specific material.
Control Unit
Advanced Image Processing System, synchronized for multiple operations and sorting mode. Adjust sorting operation to guarantee the sorting accuracy based on complex colors and shapes.
Chute System
Advanced chute design with hundreds of experiments, ensuring smooth flowing, uniform falling speed and less material consumption, optimized machine structure for disassembly and maintenance.
Ejector Valve
Italian new type of high frequency electromagnetic valve allows for accurate control of air flow power and direction with long lifetime.
Interface with Auto Testing
Self-developed auto diagnosis function with touching screen, automatically operate the testing of injector, pressure, camera, control board, background LED light and others when starting up.
Other Components
World class parts supplier, such as filter of Korea YSC and Japanese CKD. Premium quality with those famous global brands.
High Precision 10 Chutes 4.5-16 T/h PE PVC PP HDPE PET Plastic Flakes Color Sorter Machine
2.We also provide lifetime professional training and technical guidance service.
FAQ
1.Q:How about engineers service oversea?
A:Engineers available to service machinery overseas.
2.Q:How to use the machine?
A:We will supply customer the installation catalog or video online.We will ask our engineer to teach you, how to use when he go to your country to debug the machine.
3.Q:How about the sample machines for testing?
A:Sample sending for testing is welcomed.Or you send these three photos,the raw material,good material (which is you want) ,bad material (which is you want to discard).We send our video to you.
4.Q:How about the guarantee period?
A:One year.
5.Q:Will you accept L/C as payment?
A:L/C ,T/T is OK.
6.Q:Do you have any other spare parts for the customer?
A:Yes,we will supply you some spare parts.
7.Q:Which machine will work together with our color sorter which you can supply?
A:Air compressor,Air tank,Air filters,Air dryer,Light sources,Cleaning brushes,etc
